13 www.monoequip.com
Wirecut Finger Frame, Template and Dies
Hard Mix
1
Suitable for:
— Cookies
— Chocolate Chip Cookies
2
The Wirecut facility is only available on the
Omega Plus with Wirecut machine and provides
the perfect solution when a traditional ‘hand
nished’ or ‘rustic’ look is required for hard
mix biscuits.
Three separate components work together in
perfect harmony to create the distinctive qualities
only associated with Wirecut products – the
Wirecut Finger Frame, the Wirecut Template and
the Wirecut Dies.
In addition to producing a range of traditional
biscuits like cookies, biscotti and shortbread,
the Wirecut also works perfectly with suspended
ingredients and mixes containing small particulates
eg. chocolate chips. Whilst the shape and diameter
of the biscuit is determined by the Die, the thickness
of the biscuit can be programmed via the Colour
Touch Screen.
1
Wirecut Finger Frame
A very strong, tensioned stainless steel wire runs through the
front edge of the Wirecut Finger Frame, connecting one nger
to the next, to create the sharp cutting edge used to slice
through the hard dough mix. The Finger Frame is easily tted
and locked in position behind the Safety Guard.
The number of ngers on the Finger Frame is variable,
depending on the size of the machine, as is the diameter
of the extrusion and the number of dies across the template.
2
Wirecut Template
Manufactured from light-weight aluminium, the Wirecut
Template provides a solid base onto which the Wirecut
Dies are xed. The design of the template means that
a large variety of biscuits can be produced by simply
changing the dies.
3
Wirecut Dies
The Wirecut Die forms the extruded dough into the required
shape before it is cut and drops onto the tray. Some of the
most popular die shapes include the Heart, Oval, Bloom
and Star; customised shapes and sizes are also available
on request.
3
MONO Equipment does not recommend mixing different dies across the template.
