06MONO Equipment
Sheeting Templates
3
Staggered Template -
Soft Mix
The Staggered Template has been designed to make the
depositing of mixes like sponge in to round cake tins as
efcient as possible.
Round cake tins are usually arranged on a baking tray in a
staggered formation to maximise the use of space. The three
plastic nozzles attached to the aluminium Staggered Template
are set at forward facing and backward facing angles to
enable three tins to be lled simultaneously - effectively lling
two rows of cake tins in one pass.
The Staggered Template can also be produced to suit
individual requirements and non-standard tray widths.
2
Suitable for:
— All Tray Bakes
The Omega Confectionery Depositors remove
much of the manual labour traditionally
associated with the manufacture of sheet
products, providing increased production output
and greater product exibility. The precise
accuracy of the Omega Depositors also removes
human error to ensure that product consistency
of size, weight and quality is always guaranteed.
1
Sheeting Template -
Soft Mix
The Sheeting Template is perfect for laying down a single
deposit of mix onto a baking tray. The actual quantity of mix
deposited can be pre-programmed to achieve the desired
sheet thickness to create the ultimate Swiss rolls, Genoese
sponges and roulades.
Manufactured in light-weight aluminium, the Sheeting
Template is available in three standard sizes with a 385 mm,
435mm or 565mm slot length. Within each of the template
sizes there is a comprehensive range of standard slot widths,
in 1mm increments, from 2 mm to 19mm to suit the vast
majority of requirements. A Reduced Drip Sheeting Template
is also available which minimises seepage between trays.
Non-standard Sheeting Templates can also be produced to
suit individual slot length, width and position requirements.
2
Multi-Sheeting Template -
Soft Mix
The Multi-Sheeting Template provides the perfect solution
when a number of separate deposits are required across
the baking tray.
The standard range of Multi-Sheeting Templates offers 16
variations based on the number of outlets across the template,
the slot length, the slot width and the pitch between outlets.
Outlet numbers vary from just 2 on the 400mm machine to a
maximum of 9 on the 580mm machine.
Non-standard Multi-Sheeting Templates can also be
produced to suit individual outlet number, slot length, width
and pitch requirements.
1
Suitable for:
— Sponge Sheets
— Swiss Roll
— Angel Cake
— Genoese
— Chocolate Brownies
— Battenburg
— Carrot Cake
3
Suitable for:
— All 6” Sponge Tins
