ROSSELLA pLuS - NICOLETTA - GISELLA
7192450 17
• Convection: (70%) the air passage through the double mantel of the stove releases heat into the environment;
• Irradiation (30%): through the panoramic glass and the external hot surfaces of the stove, the heat is radiated into the environment.
( See chapter CALCULATION OF THE THERMAL POWER).
The stove is equipped with controls of primary and secondary air by which it is adjusted the combustion air.
1A - PRIMARY air register (Picture 6 at page 61)
With the register below on the left of the door of the hearth it is adjusted the passage of air through the drawer of ash and the grate in the
fuel direction. The primary air is necessary for the combustion process. The ash drawer must be regularly emptied, so that the ash does
not obstruct the primary air entry for the combustion. Through the primary air the re is also kept alive.
During wood combustion, the register of primary air must be opened only for a while, because otherwise the wood burns fast and the
stove may overheat. The register is open when the lever is completely pulled out. The register is closed when the lever is introduced (see
chapter NORMAL OPERATION).
2A - SECONDARY air register (Picture 6 at page 61)
Over the hearth door there is the secondary air register. Also this control must be opened (then moved to the right), especially for wood
combustion, so that unburnt carbon does not undergo a post-combustion (see chapter NORMAL OPERATION).
The adjustment of the registers necessary to reach the rated caloric yield is the following one:
Hourly wood consumption Kg/h PRIMARY air SECONDARY air TERTIARY AIR
ROSSELLA Plus 2.3
CLOSED OPEN PRE-ADJUSTED
ROSSELLA Plus Forno 2.3
CLOSED OPEN PRE-ADJUSTED
NICOLETTA
2.3
CLOSED OPEN PRE-ADJUSTED
NICOLETTA Forno
2.3
CLOSED OPEN PRE-ADJUSTED
GISELLA 2.4 CLOSED OPEN PRE-ADJUSTED
6. FLUE
Essential requirements for correct appliance operation:
• the internal section must preferably be circular;
• the appliance must be thermally insulated and impermeable and built with suitable materials which are resistant to heat, combustion
products and any condensation;
• there must be no narrowing and vertical passages with deviations must not be greater than 45°;
• if already used, it must be clean;
• the technical data from the instruction manual must be respected;
If the ues are of a square or rectangular section, the internal edges must be rounded with a radius of not less than 20 mm.
For the rectangular section, the maximum ratio between the sides must be ≤ 1.5.
A section which is too small causes a reduction in draught. A minimum height of 4 m is advisable.
The following materials are FORBIDDEN and compromise the good operation of the appliance: asbestos cement, galvanised steel, rough
and porous internal surfaces. Picture 1 at page 58 shows some example solutions.
The minimum section must be 4 dm
2
(for example 20x20 cm) for appliances whose pipe dimensions are less than 200 mm, or 6.25
dm
2
(for example 25x25 cm) for appliances with a diameter of more than 200 mm.
The draught created by your ue must be sufcient but not excessive.
A section of the ue which is too large can present a volume which is too large to heat and therefore cause operating difculties for the
appliance; to avoid this, it is necessary to intubate the appliance for its entire height. A section which is too small causes a reduction in
draught.
ATTENTION: as far as concern the realisation of the ue connection and ammable materials please follow the requirements provided by
UNI 10683 standard. The ue must be at a suitably distance from ammable or combustible material using suitable insulation or
an air space.
It is FORBIDDEN to pass system piping or air ducts inside the ue. It is also forbidden to create moveable or xed openings on the ue
itself, for the connection of further different appliances (See chapter CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE).
6.1. CHIMNEY POT
The ue draught depends on the suitability of the chimney pot.
It is therefore essential that, if built in a handcrafted way, the exit section is more than twice the internal section of the ue
(Picture 2 at page 58) .
As it must always go past the ridge of the roof, the chimney pot must ensure exhaust even in the presence of wind (Picture 3 at page 59).
The chimney pot must meet the following requirements:
• Have an internal section equivalent to that of the chimney.
• Have a useful exit section of double the internal section of the ue.
• Be built so as to prevent rain, snow or any foreign body entering the ue.
• Be easy to inspect, for any maintenance and cleaning operations.
