TERMOSUPREMA COMPACT DSA / ITALY TERMO DSA

7095802 23

The control regulation necessary in order to obtain nominal caloric output is the following (see Cap. TECHNICAL DATA):

PRIMARY air SECONDARY air TERMOSTAT

TERMOSUPREMA CPT - DSA 1/4 OPEN OPEN 3

ITALY TERMO - DSA 1/4 OPEN OPEN 3

D - FLUE GAS Control (Picture 7 at page 84 )

(Conversion from the cooker HOTPLATE USE – OVEN USE function to the cooker HEATING function)

In the central part of the instrument panel, there is the ue gas control, which can be recognised from its enamelled, labelled knob.

This control must only be used to facilitate the ignition of fuel in the cooker. Pull the lever outwards from the cooker (control open).

IMPORTANT : during normal cooker operation, the control lever must remain completely inserted (pushed inwards on the cooker). In

this way avoiding excessive fuel consumption and poor thermocooker output (control closed).

To ignite the ame follow the instructions below (see Cap. IGNITION) :

• Open the ignition control to aid ue gas exhaust. Position the control (any buttery valve placed on the ue gas exhaust pipe must also

be opened).

• Position the thermostat knob on position 5 (maximum opening).

• Open the primary air control (placed on the ash tray).

• After having started the re with small pieces of wood and waited until it is well lit, adjust the thermostat to the positions corresponding

to the desired heat (0÷5).

7. FLUE

Essential requirements for correct appliance operation:

• the internal section must preferably be circular;

• the appliance must be thermally insulated and impermeable and built with suitable materials which are resistant to heat, combustion

products and any condensation;

• there must be no narrowing and vertical passages with deviations must not be greater than 45°;

• if already used, it must be clean;

• the technical data from the instruction manual must be respected;

If the ues are of a square or rectangular section, the internal edges must be rounded with a radius of not less than 20 mm.

For the rectangular section, the maximum ratio between the sides must be ≤ 1.5.

2

The draught created by your ue must be sufcient but not excessive.

A section of the ue which is too large can present a volume which is too large to heat and therefore cause operating difculties for the

appliance; to avoid this, it is necessary to intubate the appliance for its entire height. A section which is too small causes a reduction in

draught.

ATTENTION: as far as concern the realisation of the ue connection and ammable materials please follow the requirements provided by

UNI 10683 standard. The ue must be at a suitably distance from ammable or combustible material using suitable insulation or

an air space.

It is FORBIDDEN to pass system piping or air ducts inside the ue. It is also forbidden to create moveable or xed openings on the ue

itself, for the connection of further different appliances (See chapter CONNECTING A FIREPLACE OR OPEN HEARTH TO THE FLUE).

• Have an internal section equivalent to that of the chimney.
