La Nordica Focolare 80 Idro Crystal D.S.A [23/76] Low emission fire lighting

paint. This paint, although during the manufacture it is backed at 250 °C for some hours, must exceed many times and for a given

period of time the temperature of 350 °C before becoming completely embedded in the metallic surfaces.

Therefore, it is extremely relevant to take these easy steps during the lighting:

1. Make sure that a strong air change is assured in the room where the appliance is installed.

2. During the rst starts, do not load excessively the combustion chamber (about half the quantity indicated in the instructions manual)

and keep the product continuously ON for at least 6-10 hours with the registers less open than the value indicated in the instructions

manual.

3. Repeat this operation for at least 4-5 or more times, according to your possibilities.

4. Then load more and more fuel (following in any case the provisions contained in the installation booklet concerning maximum load)

and, if possible, keep the lighting periods long avoiding, at least in this initial phase, short ON/OFF cycles.

5. During the rst starts, no object should be leaned on the appliance and in detail on enamelled surfaces. Enamelled surfaces must

not be touched during heating.

6. Once the «break-in» has been completed, it is possible to use the product as the motor of a car, avoiding abrupt heating with

excessive loads.

After testing the proper working of the appliance, some days from the installation, it is possible to proceed with the construction

of its aesthetic covering.

WARNING: During the surround building operations it must kept in mind possible and subsequent electrical installed parts maintenance

(Fans, temperature probe, etc) and with hydraulic systems all parts connected to the thermo-replace.

7.1. LOW EMISSION re lighting

Smokeless combustion is a way of lighting a re able to signicantly reduce the emission of harmful substances. The wood burns gradually

from the top downwards, so combustion is slower and more controlled. Burnt gases pass through the high temperatures of the ame and

therefore burn almost completely.

Place the logs in the hearth a certain distance apart as shown in the Picture 13 at page 70. Arrange the largest at the bottom and the

smallest at the top, or vertically in the case of tall narrow combustion chambers. Place the re starter module on top of the pile, arranging

the rst logs in the module at right angles to the pile of wood.

Fire STARTER MODULE. This re starter module replaces a paper or cardboard starter. Prepare four logs, 20 cm long with a cross section

of 3 cm by 3 cm Picture 13 at page 70. Cross the four logs and place them on top of the pile of wood at right angles, with the re lighter (wax

impregnated wood bre for example) in the middle. The re can be lit with a match. If you want, you can use thinner pieces of wood. In this

case, you will need a larger quantity. Keep the ue gas exhaust valve and combustion air regulator open.

After lighting the re, leave the combustion air regulator open in the position shown:

FUEL Primary AIR Aria SECONDARIA

Wood CLOSED 1/2 OPEN

IMPORTANT:

• do not add further wood between one complete load and the next;

• do not suffocate the re by closing the air intakes;

• regular cleaning by a chimney sweep reduces ne particle emissions.

These instructions are backed by ENERGIA Legno SVIZZERA www.energia-legno.ch

8. NORMAL OPERATION

After having positioned the registers correctly, insert the indicated hourly wood load avoiding overloads that cause anomalous stresses

and deformations. You should always use the product with the door closed in order to avoid damages due to overheating (forge

effect). The inobservance of this rule makes the warranty expire.

IMPORTANT: For safety reasons the door of the hearth can be opened only for the loading of the fuel. The hearth door must

always remain closed during operation or rest.

With the registers located on the front of the device, it is possible to adjust the heat emission of the same. They have to be opened

according to the caloric need. The best combustion (with minimum emissions) is reached when, by loading the wood, most part of the air

for combustion ows through the secondary air register.

Never overload the appliance. Too much fuel and too much air for the combustion may cause overheating and then damage the

product. You should always use the appliance with the door closed in order to avoid damages due to overheating (forge effect).

The adjustment of the registers necessary to reach the rated caloric yield is the following one: see chap. TECHNICAL DESCRIPTION.

The appliance works as an intermittent operating appliance.

In the event that the water temperature exceeds the tripping temperature of the safety devices, immediately suspend the feeding

of wood, and make sure that the water temperature and the ame decrease, eliminating the causes of the overheating (if necessary

by closing the air register).

If the water system is connected in the thermo-replace, the hot water tap can be opened to speed up the cooling of the appliance.

Besides the adjustment of the air for the combustion, the intensity of the combustion and consequently the thermal performance of the

device is inuenced by the stack. A good draught of the stack requires a stricter adjustment of air for combustion, while a poor draught

requires a more precise adjustment of air for combustion.

To verify the good combustion, check whether the smoke coming out from the stack is transparent.

If it is white, it means that the device is not properly adjusted or the wood is too wet; if instead the smoke is gray or black, it signals that the

combustion is not complete (it is necessary a greater quantity of secondary air).

WARNING: When fuel is added onto the embers in the absence of a ame, a considerable amount of fumes may develop. Should this

happen, an explosive mixture of gas and air may form, and in extreme cases an explosion may occur. For safety reasons it is advisable

to perform a new lighting procedure with the use of small strips.

FOCOLARE 80 IDRO CRYSTAL - DSA

6097811 23
