Mitsubishi Electric PAC-YT52CRA [7/24] Preset temperature

– 7 –

In COOL, DRYING, HEAT, and AUTO (single set point) modes

Pressing the button increases the preset temperature.

Pressing the

button decreases the preset temperature.

In AUTO (dual set point) mode

* During the preset temperature setting, the setting will automatically turn off if the or

button is left untouched for a certain period of time.

Preset temperature

Cooling preset temperature

Heating preset temperature

Current operation mode

Current preset temperature (cooling/heating) appears.

When the or button is pressed, the preset temperature

(cooling/heating) display blinks.

While the preset temperature (cooling/heating) display blinks, pressing the

button increases the preset temperatures for both cooling and

heating, and pressing the button decreases the preset temperatures

for both cooling and heating.

When the button is pressed, only the cooling preset temperature display

blinks.

While the cooling preset temperature display blinks, pressing the

button increases the cooling preset temperature, and pressing the

button decreases the cooling preset temperature.

When the button is pressed, only the heating preset temperature display

blinks.

While the heating preset temperature display blinks, pressing the

button increases the heating preset temperature, and pressing the

button decreases the heating preset temperature.

Pressing the button completes the preset temperature setting.
