![Lincat CG6nFL [9/12] Fault finding](/views2/1337479/page9/bg9.png)
IS205 ECN3592
9
Is there gas at the burner?Yes No
Are thermocouple connections loose?
Is the thermocouple voltage less than 15mV?
Is the valve damaged?
Check injector for blockages
Tighten connections
Replace valve
Yes
Yes
Yes
No
No
No
Replace thermocouple
Recheck system
Injector
Remove the control knobs and fascia panel.
Loosen the burner pipe nut (JJ) at the valve (FF) and at the elbow (LL).
Remove the screws at the elbow retaining bracket (KK).
Remove the injector (MM) with the copper and fibre washers.
Fit new parts and re-assemble.
Perform gas soundness test of circuit prior to operation of appliance.
Description
Part number
Burner
BU28
Copper washer
CO113
Locknut
CO53
Male stud elbow
CO85
Foot
FE37
Cooking grid handle
HA50
Injector Natural gas
JE28
Injector Propane gas
JE45
Control knob
KN184
Pressure governor
PG10
Thermocouple
TC14
Gas valve
VA09
Fibre washer
WA08
Burner/s will not light or stay lit
SPARE PARTS LIST
FAULT FINDING
