ILLUSTRATED PARTS LIST IP54
D500, ILLUSTRATED PARTS/RECOMMENDED PARTS 120717A
ITEM # PART # DESCRIPTION
1 WC-314
3,4,5
POWER BLOCK, 5 STATION (NOT SHOWN)
2A WC-889
1,2,4,5
VALVE, DUMP LEFT 120V 12W ALPHA’S/D1000/
GEM-12/TLP
2B WC-860
3
VALVE, DUMP LEFT 240V 12W
3 WC-3518 LEG, GLIDE 3/8”-16 STUD SCREW
4A WC-2962K
a
KIT, FITTING SPRAYHEAD SS
4B WC-2962-101K
b
KIT, FITTING SPRAYHEAD KYNAR
5 WC-1806 SEAT CUP, SILICONE USE ON WC-1809 FAUCET
6 WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
7A WC-774
1,2,4,5
CONTROL MODULE, UCM 120V ALPGT/D500GT/
D60GT
7B WC-724
3
CONTROL MODULE, UCM 220V ALPGT D500GT/
D60GT
7C WC-37064
1,2,4,5
KIT, LABEL & UCM D500GT/H THERMAL ALPHA
CURTIS (INCLUDES ITEMS 7A AND 8)
7D WC-37348
3
KIT, LABEL & UCM D500GT 220V (INCLUDES
ITEMS 7B AND 8)
8 WC-39346
LABEL, UCM OVERLAY D500GT/H D60GT
CURTIS
9 WC-29025 SPRAYHEAD, PURPLE ADVANCE FLOW
10 WC-8556
HEATSINK, ASSY DV ALPDS/D500AP TCTD/
PTTD
11A WC-3316
BREW CONE, W/HANDLE ASSY 7.1”D.W/WC-
3317 & WC-3323 ALP/AP
11B WC-3621-101
BREW CONE, NON-METAL UNIVERSAL (WITH
SPLASH POCKET)
12A WC-6217
1,3,4
COVER, FRONT SS D500GT
12B WC-6225
2,5
COVER, FRONT C250/C/D500-APT
13 WC-2401K KIT, ELBOW 3/8 NPT X 1/4 FLARE
14 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
15A WC-1200
1,2,4,5
CORD, 14/3 SJTO 6’ BLK W/PLUG
15B WC-1231-102
3
CORD, 2.5 mm² 90ºC 36A 450/750 V STRIPPED
W/FERRULES ONE END
ITEM # PART # DESCRIPTION
16A WC-13237
1,2
HARNESS, ASSY D500GT/H-10
16B WC-13282
3
HARNESS ASSY, D500GT/H-30 (TERMINAL
BLOCK INCLUDED)
16C WC-13322
4,5
HARNESS, ASSY D500GT/H-63 DUAL VOLTAGE
(TERMINAL BLOCK INCLUDED)
17 WC-29044-101 SLEEVE, OVERFLOW
18A WC-4213
a
NUT, 5/8 LOCK PLATED
18B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
19A WC-826L
1,2,4,5
VALVE, INLET 1 GPM 120V 9W
19B WC-856
3
VALVE, INLET 1 GPM 240V 6W
20 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
21 WC-5231 COMPOUND, SILICONE 5 OZ
22A WC-102
1,2
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
22B WC-103
3,4,5
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
23A WC-58117
COVER, TOP ALPGT/D500GT/D60GT TLP/TCTS/
CBS/GEMSS
23B WC-5450
COVER, TOP ALPHA-1DS,3DSL,3DSR GEM-
120A/200R/230A/300IL/600IL (OLDER MODELS)
24 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
25 WC-37252
KIT, HOT WATER FAUCET REPLACEMENT
ALPGT/D60GT/D500GT
26A WC-8591
1,2,4,5
CAPACITOR, X2 USED ON ALL ADS MODELS
26B WC-8609
3
CAPACITOR, 2.2 UF 250/275 VACS 50/60 ALL
ARU’S
27 WC-596K
3
KIT, NOISE FILTER EMI 250V/30A 1PH
28A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
28B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
D500GT/ D500GTH - Main Chassis - Parts List
ITEM # PART # DESCRIPTION
2A WC-889
VALVE, DUMP LEFT 120V 12W ALPHA’S/D1000/
GEM-12/TLP
6 WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
7C WC-37064
KIT, LABEL & UCM D500GT/H THERMAL ALPHA
CURTIS (INCLUDES ITEMS 7A AND 8)
9 WC-29025 SPRAYHEAD, PURPLE ADVANCE FLOW
ITEM # PART # DESCRIPTION
19A WC-826L VALVE, INLET 1 GPM 120V 9W
20 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
21 WC-5231 COMPOUND, SILICONE 5 OZ
22 WC-103
SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC
RESISTIVE
26 WC-8591 CAPACITOR, X2 USED ON ALL ADS MODELS
D500GT/ D500GTH - Recommended Parts to Stock
1
D500GT12,
2
D500GTH12,
3
D500GT30,
4
D500GT63,
5
D500GTH63
a
1HZHUXQLWV6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWKROGHUXQLWV
b
Older units.
