CONTROL PANEL
4
5
IMPORTANT NOTES!
Vitamix machines come with several dierent control options.
Please be sure you are following the instructions for your model.
MOUNTING KITS: Mounting Kits, with detailed instructions, are available for
both the countertop and wall mount Mix’n Machines. See Parts Lists on
page 17 and 19 for kit details.
Mix’n Machine Advance Timer Model
Pre-programmed with one pre-set blending cycle.
COUNTERTOP
ON/OFF Power Switch: This is a lighted switch. When light is lit, power is ON.
Located on the front of the machine, the ON/OFF switch controls the power to the
machine. While plugged in, switch to ON to ready the machine for blending. Shut
OFF the power switch at night or whenever the machine will be left unattended.
START Actuator: The actuator starts the agitator and begins a pre-set timed blending
cycle when the machine is ON. Push the actuator to activate a timed blending cycle.
The machine will shut o automatically at the end of the pre-set time. AGITATOR.
When the machine is turned ON and the actuator is pushed, the agitator spins and
mixes the product and other ingredients. (See page 12 for available agitators.)
LED Indicator Light: The LED light blinks when a blending program is 4 seconds
from completion so that excess product can be spun o the agitator. The blinking
light will get progressively faster to indicate that the program cycle is almost
complete. When a new program is installed using a programming chip, the light
blinks to indicate acceptance.
Mix’n Machine Advance Programmable Model
Pre-programmed with six blending options and pulse switch.
COUNTERTOP
ON/OFF Power Switch: This is a lighted switch. When light is lit, power is ON.
Located on the front of the machine, the ON/OFF switch controls the power to the
machine. While plugged in, switch to ON to ready the machine for blending.
Shut OFF the power switch at night or whenever the machine will be left unattended.
START Actuator: The actuator starts the agitator and begins a blending cycle when
the machine is ON. Push the actuator to activate a program setting. The machine will
shut o automatically at the end of the program setting.
AGITATOR: When the machine is turned ON and the actuator is pushed, the agitator
spins and mixes the product and other ingredients. (See page 12 for available agitators.)
PROGRAM Dial: The PROGRAM dial allows user to select a number of pre-programmed
settings. Machine will shut o automatically at the end of the program. Program is
activated only when the power switch is ON. See page 10 for programming details.
PULSE Switch: The PULSE switch starts the agitator and can be used to quickly
refresh product. Depress the switch and hold down as long as needed. The PULSE
switch can only be used when the power switch is ON.
LED Indicator Light: The LED light blinks when a blending program is 4 seconds
from completion so that excess product can be spun o the agitator. The blinking
light will get progressively faster to indicate that the program cycle is almost
complete. When a new program is installed using a programming chip, the light
blinks to indicate acceptance.
Indicator Light
Power Switch
Actuator
Agitator
Indicator Light
Power Switch
Actuator
Agitator
Program Dial
Pulse Switch
