- The exchange is based on 10 circuits and can be extended up to 240 circuits
by adding circuits required for the user.
- The exchange is used being connected to telephones manufactured by the
company. It may also be connected to general telephones.
- You can use DC 24V/1A power supply when AC220V is not available.
－5－
2. Features
1) The Unit
3. The Unit and Functions
No Description No Description
1
2
3
4
5
6
7
8
9
10
11
12
Telephone manufactured by the
company(TP-K or TP-S)
Telephone connector jack
Household lamp
Power lamp
Calling button
Call connection key
Master calling lamp, name
card(Address indication)
Power cord
DC input port
FUSE
Power switch
Slave connection port
