4. Signal and Lamp Specification.

5. How to use and function

If the situation will occur simultaneously, corridor light and master station lamp will blink at once.

(Corridor light, shower room, bed, interphone will blink by turns)

(

)

5-1-1. Call a handset in bed or press the dial button to answer the call.

- Pick up the receiver -> Input a sick room and BED number -> Call(#) -> Talk

- Pick up the receiver -> Shortcut button -> Talk

- Speaker phone -> Input a sick room and BED number -> Call(#) -> Talk

- Speaker phone -> Shortcut button -> Talk

- Shortcut button -> Pick up the receiver -> Talk

5-1-2.

When you finish the conversation, please hang off the handset.

5-1-3.

While in conversation, Green led lamp will turn on and Call xxxx-Bed No will be displayed.

5-2-1. Communication with master and sub station.

- Press the call button in sub station to communicate with master station, and then green lamp will

be lighted and white lamp in corridor will be lighted(in that case, the Led lamp in master station 

alarm is warning).

- Press the cancel switch to cancel the communication in sub station (LED in master station display

as Sub cancel REQ).

Section LCD LED SOUND Corridor Light

Communication Call: XXXX

Steady Green

Bed Paging Call: XXXX

Flashing Green

Melody Sound

Flashing White

Toilet(Room) Emerg: XXXX Flashing Red Emer. Sound Flashing Red

Toilet(Corridor) Emerg: XXXX Flashing Red Emer. Sound Steady Red

Presence S/W Steady Green Steady White

Staff Paging Staff: XX Flushing Ginger Police Sound Steady White

Flashing Red

Interphone

Process AN90:XX
