ASRock A320M-DGS SOCKET AM4 AMD A320 2XDDR4 [45/87] Italian
![ASRock A320M-DGS SOCKET AM4 AMD A320 2XDDR4 [45/87] Italian](/views2/1352255/page45/bg2d.png)
AB350M-HDV/A320M-HDV/A320M-DGS
43
Italiano
Italiano
Speciche
Piatta-
forma
•
Fattore di forma Micro ATX
•
Design condensatore solido
CPU
•
Supporta APU serie A (Bristol Ridge) e CPU serie Ryzen
(Summit Ridge) AMD Socket AM4
•
Digi Power design
•
Potenza a 7 fasi
•
Supporto di CPU no a 65W
Chipset
•
AMD Promontory B350 (AB350M-HDV)
•
AMD Promontory A320 (A320M-HDV/A320M-DGS)
Memoria
•
Tecnologia memoria DDR4 Dual Channel
•
2 x alloggi DIMM DDR4
•
Le CPU serie AMD Ryzen supportano DDR4
3200+(OC)/2933
(OC)
/2400/2133 CEE e non ECC, senza buer*
•
Le APU serie AMD 7a Gen A supportano DDR4
2400/2133
CEE
e non ECC, senza buer*
* Per maggiori informazioni fare riferimento all’elenco dei supporti di
memoria sul sito di ASRock. (http://www.asrock.com/)
* Fare riferimento a pagina 23 per il supporto della frequenza
massima DDR4 UDIMM.
•
Capacità max. della memoria di sistema: 32 GB
•
Contatti d’oro 15μ negli alloggi DIMM
Alloggio
d’espan-
sione
•
1 x PCI Express 3.0 x16 slot (PCIE2 @ modalità x16)*
* Supporto di SSD NVMe come disco d’avvio
* Le CPU serie AMD Ryzen supportano PCIE2: modalità x16
* Le APU serie AMD 7a A supportano PCIE2: modalità x8
•
1 alloggio PCI Express 2.0 x1
Graca
•
Graca AMD Radeon
TM
serie R7 in APU serie A/E
•
DirectX 12, Pixel Shader 5.0
•
Memoria condivisa max. 2GB
AB350M-HDV/A320M-HDV:
•
Tre opzioni di output graco: D-Sub, DVI-D e HDMI
•
Supporto di tre monitor
