ASRock A320M-DGS SOCKET AM4 AMD A320 2XDDR4 [82/87] Indonesian
![ASRock A320M-DGS SOCKET AM4 AMD A320 2XDDR4 [82/87] Indonesian](/views2/1352255/page82/bg52.png)
80
Bahasa Indonesia
Spesikasi
Platform
•
Bentuk dan Ukuran Micro ATX
•
Desain Kapasitor Solid
CPU
•
Mendukung Soket AMD APU Seri AM4 A (Bristol Ridge) dan
CPU Seri Ryzen (Summit Ridge)
•
Digi Power design
•
Desain 7 Fase Daya
•
Mendukung CPU hingga 65W
Chipset
•
Promontory AMD B350 (AB350M-HDV)
•
Promontory AMD A320 (A320M-HDV/A320M-DGS)
Memori
•
Teknologi Memori DDR4 Dua Kanal
•
2 x Slot DIMM DDR4
•
CPU Seri AMD Ryzen mendukung DDR4 3200+(OC)/2933
(OC)/2667/ 2400/2133 ECC & non-ECC, memori tanpa buer*
•
AMD APU Seri A Generasi ke-7 mendukung DDR4 2400/2133
ECC & non-ECC, memori tanpa buer*
* Untuk informasi lebih lanjut, lihat Daar Dukungan Memori di
situs web ASRock. (http://www.asrock.com/)
* Lihat halaman 23 untuk dukungan frekuensi maksimum DDR4
UDIMM.
•
Kapasitas maksimum memori sistem: 32GB
•
15μ Bidang Kontak berwarna Emas di Slot DIMM
Slot Ek-
spansi
•
1 x Slot PCI Express 3.0 x16 (mode PCIE2 @ x16)*
* Mendukung SSD NVMe sebagai disk boot
* CPU Seri AMD Ryzen mendukung PCIE2: x16 mode
* AMD APU Seri A Generasi ke-7 mendukung PCIE2: x8 mode
•
1 x Slot PCI Express 2.0 x1
Gras
•
Gras AMD Radeon
TM
Seri R7 terpadu dalam APU seri A/seri E
•
DirectX 12, Pixel Shader 5.0
•
Maksimum memori bersama 2GB
AB350M-HDV/A320M-HDV:
•
Tiga pilihan output gras: D-Sub, DVI-D, dan HDMI
•
Mendukung Tiga Monitor
