AB350M-HDV/A320M-HDV/A320M-DGS
45
Italiano
Italiano
•
Connettori audio HD: Ingresso linea / altoparlante frontale /
microfono
AB350M-HDV/A320M-HDV:
•
1 x porta D-Sub
•
1 x porta DVI-D
•
1 x porta HDMI
A320M-DGS:
•
1 x porta DVI-D
Archiviazi-
one
•
4 x connettori SATA3 6,0 Gb/s, supporto RAID (RAID 0, RAID
1, e RAID 10), NCQ, AHCI e Hot Plug
•
1 x Ultra M.2 Socket, supporta i moduli M.2 SATA3 6,0 Gb/s di
tipo 2242/2260/2280 chiave M e moduli M.2 PCI Express no
a Gen3 x4 (32 Gb/s) (con CPU serie Ryzen) o Gen3 x2 (16 Gb/s)
(con APU serie A)*
* Supporto di SSD NVMe come disco d’avvio
* Supporta kit ASRock U.2
Connet-
tore
•
1 x connettore porta stampa
•
1 x connettore porta COM
•
1 x connettore TPM
•
1 x collegamento altoparlante e intrusione telaio
•
1 x connettore ventola CPU (4-pin)
•
2 connettori ventola telaio (1 x 4 pin, 1 x 3 pin)
* Il connettore ventola CPU supporta ventole CPU con potenza
massima di 1 A (12 W).
•
1 x connettore alimentazione ATX 24 pin
•
1 x connettore alimentazione 12 V 4-pin
•
1 x connettore audio pannello frontale
•
2 x connettori USB 2.0 (supporto di 4 porte USB 2.0) (supporta
protezione da scariche elettrostatiche)
•
1 x connettore USB 3.0 (supporto di 2 porte USB 3.0) (supporta
protezione da scariche elettrostatiche)
Funzional-
ità BIOS
•
AMI UEFI Legal BIOS con interfaccia di supporto
•
Supporta “Plug and Play”
•
Eventi di riattivazione conformi a ACPI 5.1
•
Supporta jumperfree
•
Supporto di SMBIOS 2.3
•
Regolazione variabile tensione DRAM
