DESCRIPTION: REMOTE TEMPERATURE SENSOR

(see page 3)

A. LED INDICATOR

Flashes once when the device transmits data.

Flashes twice when batteries should be replaced.

B. BATTERY COMPARTMENT

2 x AA size batteries should be inserted.

C. RESET BUTTON

Resets the device settings to the original factory settings.

D. CHANNEL BUTTON

You should select the data transmission channel before inserting batteries into the

battery compartment.

E. WALL MOUNT APERTURE

F. CELCIUS/FAHRENHEIT SWITCH BUTTON

GETTING STARTED

For the device to work properly:

1. Using the CHANNEL switch, select the data transfer channel, then insert batteries

into battery compartment.

2. Place the remote temperature sensor within the data transfer distance, as close as

possible to the clock body.

3. Position the multifunctional clock and the remote temperature sensor in places

with minimum interference noise for better data transfer.

Take into account that the data transfer distance of the remote temperature sensor

transmitter (usually 1015 m) depends on the material of walls in the building and

their quantity. Try several variants of placing the clock. Despite the remote temper

ature sensor is weatherproof, it must be placed away from the direct sunlight, rain

or snow.

Inserting Batteries: Remote Temperature Sensor

1. Turn off the screws on the battery compartment cover.

2. Select the data transfer channel using the CHANNEL switch.

3. Insert 2 x UM3/AA size batteries 1.5V, observing the polarities.

4. Replace the battery compartment cover and turn up the screws.

Inserting Batteries: Multifunctional Clock

1. Open the battery compartment cover.

2. Insert 2 x UM3/AA size 1.5V batteries, observing the polarities.

3. Replace the battery compartment cover.
