GB
O w n e r ’ s m a n u a l
•
P L A T I N U M P R O
11
O w n e r ’ s m a n u a l
•
P L A T I N U M P R O
Spare parts list
Buble Description Qty
1 Main frame 1
2 Front support post 1
3 Rear support post 1
4 Handlebar post 1
5 Seat post 1
6 Handlebar 1
7 Sliding seat mount 1
8 Sliding handlebar mount
(front) 1
9 Braking pad holder 1
10 Brake pad - wool felt 1
11 Bushing 1
12 Nut 1
14 Spring (Ø13×Ø10×16L) 2
15 Nut (M10x3T) 2
16 Brake tension knob 1
18 Phillips head screw
(M6×15m/m) 4
19 Quick release lever
(8×40m/m) 2
20 Quick release lever
(8×25m/m) 2
21 Handlebar locking blocks 4
22 Flat washer (5/1”×35×3.0T) 1
23 Bottle holder 1
25 Pedal pair 1
26 Anti rotation washer 1
27 Seat 1
29 Tapping screw (5×16m/m) 2
30 Sheet metal screw
(3.5×12m/m) 3
31 Flywheel (& 32~38,66,68) 1
32 Bearing housing 2
33 Flywheel Axle 1
34 Woodruff key (5×18L) 1
35 Flywheel pulley (Ø66×22m/m) 1
36 Button head socket bolt
(5/16”×3/4”) 1
37 Flat washer (5/16”×20×3.0T) 2
38 Button head socket bolt
(5/16”×3/4”) 6
39 Phillips head screw
(M6×10m/m) 6
40 Belt 1
41 Flywheel pulley
(Ø209×21m/m) 1
42 Crank arm (L) 1
43 Crank arm (R) 1
44 Crank arm end cap (M22×1.0/
Ø23) 2
45 Crank axle 1
46 Button head socket bolt
(5/16”×1/2”) 5
48 Flat washer (5/16”×16×1T) 4
49 Split washer (5/16”×1.5T) 4
50 Transport wheel 2
53 Foot pad (& 54,72,79) 4
54 Nut 3/8” 4
55 Support post end cap 4
56 Lower tube sleeve 2
57 Upper seat tube sleeve 2
58 Bottom end cap, eye tube 2
59 Rear support post cover 1
60 Chain cover (RH) 1
61 Chain cover (LH) 1
62 Flywheel cover 1
63 Pulley cover 1
65 Bearing (6203) 2
66 Bearing (6004) 4
67 C Ring Ø17 1
68 C Ring 3
69 Hex head bolt (1/4”×3”) 1
70 Hex head bolt (1/4”) 1
71 Nyloc nut (1/4”×5.5T) 1
72 Flat head socket bolt (3/8”×2”) 2
73 Star washer (25.5×Ø16) 1
74 Belt tightener axle (&
65,67,69,70,71) 1
75 Belt tightener carriage bolt 1
77 Foam stop handle bar tube
(30×60×4T×63L) 1
78 Flat washer (Ø5/16”×23×2T) 1
79 Flat washer (3/8”×19×1.5T) 2
80 Nut (M10×1.25m/m) 2
81 Carriage bolt (3/8”×3-1/2”) 4
82 Cap nut (3/8”) 4
