Tunturi Classic Bike U 1.0 [4/10] Maintenance

4 5

CONSOLE

KEYS

1. ENTER

Selection of the goal values

2. ”+ / -”

Setting the goal values, increasing the intensity (+),

decreasing the intensity (-)

3. RESET.

Single push resets values. Long push restarts the meter.

4. RECOVERY

Calculates your recovery heart rate index.

DISPLAY

Small window: Speed (km/h or ml/h), RPM (revolutions

per min), time (mm:ss), distance (km or ml), energy

consumption (kcal) and heart rate (bpm) are displayed.

Big window: Starts automatically scan between the values

of time – distance – energy – heart rate – RPM – speed

every 6 seconds. Scanning can be stopped by pressing

ENTER button. By pressing ENTER again you can change

the big window information to the next.

PROGRAMS

1.MANUAL PROGRAM

Set target time and/or distance and/or energy

consumption and/or upper heart rate limit by +/- ENTER.

Start training by pedaling.

If you have set target/targets, the target/targets start to

count down.

2. RECOVERY

Start the recovery calculation after training by pressing

RECOVERY button. Recovey heart rate calculation can

be started only if the heart rate measurement is activated

and the heart rate value is shown on the display The

measurement takes 60 seconds. After 60 seconds, the

display shows your recovery index F1-F6 (F1 = best result).

To get back to main menu, press RECOVERY button once

again.

SETTING THE DATE AND TIME

After pressing ENTER+RESET for 2 seconds, the meter

restarts and you can use SELECTION DIAL to set the time.

ADDITIONAL NOTES

1. For speed and distance you can choose either metric

or English units by using the KM/ML switch located on the

back cover of the meter. Batteries have to be reinstalled

to apply the change.

2. If you are not training and buttons are not pressed, the

meter switches into the sleep mode after four minutes.

Room temperature, date and time are displayed.

3. Entering training targets (time, distance, energy, heart

rate limit) is possible only in the STOP mode (not during

training).

4. When you are in STOP mode, Pause-symbol (P) is

displayed on the upper left corner of the display.

5. SCAN symbol is displayed on the upper left corner of

the display, when scan function is on. You can switch the

scan function off by pressing ENTER.

6. This equipment cannot be used for therapeutic

purposes.

7. Energy expenditure is calculated based on average

values. The energy expenditure is displayed in kilocalories.

To convert this into joules, use the formula: 1 Kcal = 4.187

KJ.

8. If you are training with heart rate measurement you can

set maximum heart rate limit. When limit is exceeded while

training meter will give alarm beeps.

9. If you have several targets to count down, a signal

sounds when each target reaches zero. After reaching

zero each value starts to count up.

10. Note that recovery index is in relation to the heart

rate frequency in both the beginning and the end of the

measurement.

MAINTENANCE

The equipment requires very little maintenance. Check,

however, from time-to-time that all screws and nuts are

tight.

• After exercising, clean the equipment with a soft,

absorbent cloth. Do not use solvents.

• Never remove the equipment’s protective casing.

REPLACING BATTERIES

Replace the meter batteries if the meter no longer starts or

if the display becomes disturbingly dim. Remove the

battery casing cover from the back and remove the old

batteries. Insert new batteries into the battery holder and

push the battery casing cover back into place.

IMPORTANT: Note the indications + and – marked on

the battery holder.

Bike 1.0_MANUAL.indd 4 9/12/2012 3:03:13 PM
