─ 5 ─

Parts List

NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED

Item No.

Description Qty

Item No.

Description Qty

1 Front support frame 1 22 Hex Head Screw M10*25 2

2 Seat pad support frame 1 23

Button Head Socket Cap Screw M8*20

3 Rear base 1 24 Flat washer Φ11*Φ20*2 14

4 Middle support frame 1 25 Hex Head Screw M10*80 2

5 Handle frame 1 26 Hex Head Screw M10*75 2

6 Left shroud 1 27 Hex Head Screw M10*130 2

7 Seat pad 1 28 Nylon lock nut M10 6

8 Back pad 1 29 Right shroud 1

9 Plastic plate Ⅰ 2 30 Philip screw M6*15 14

10 Nylon nut 4 31 Hex nut M6 14

11 Cable 4 32 U bolt M5 4

12 Foot peg 2 33 Thin nylon nut 1/2"-13*8 4

13 Handle grip Φ28*Φ36*630 2 34 Plastic plateⅡ 2

14 Pulg RT 50*100 3 35 Hex Key S=4 1

15 Pulg Φ32 2 36 Hex Key S=5 1

16 Foot pad 3 37 Hex Key S=6 1

17 Handle grip Φ32*205 4 40 Rubber bumper 2

18 Rubber pad 1 41 Nylon lock nut M5 8

19 Philip screw ST4.2*16 2 42 Flat washer Φ13*Φ24*1.5 4

20 Flat washer Φ9*Φ16*1.6 16 43 Spring washer M10 2

21 Hex Head Screw M8*35 8 44 Wrench Φ16*117 1
