Booster function

The booster function [ B ] grants a boost of power to the selected heating zone.

If this function is activated the heating zones work during 10 minutes with an ultra high power.

The booster is foreseen for example to heat up rapidly big quantities of water, like nuddles

cooking.

 Start up / Stop the booster function:

Action Control panel Display

Zone selection press key [ 0 ] from the zone [ 0 ] and control light on

Start up the booster press key [ P ] [ P ]

Stop the booster slide on the “SLIDER“ [ P ] to [ 0 ]

or press on [ P ] [ 9 ]

 Power management:

The hole cooking hob is equipped by a maximum of power. When the booster function is activated,

and not to exceed the maximum power, the electronic system orders to reduce automatically the

power level of an other heating zone. The display is blinking on [ 9 ] during a few seconds and then

shows the maximum of power allowed :

Heating zone selected The other heating zone: (example: power level 9)

[ P ] is displayed [ 9 ] goes to [ 6 ] or [ 8 ] depending the type of zone

Timer

The timer is able to be used simultaneous with all 3 heating zones and this with different time

settings (from 0 to 99 minutes) for each heating zone.

 Setting and modification of the cooking time :

Example for 16 minutes at power 7 :

Action Control panel Display

Zone selection press display [ 0 ] selected [ 0 ] and control light on

Select the power level slide on the “SLIDER“ to [ 7 ] [ 7 ]

Select “Timer” press display [ CL ] [ 00 ]

Set the units slide on the “SLIDER“ to [ 6 ] [ 0 fixed ] [ 6 blinking ]

Valid the units press display [ 06 ] [ 0 blinking ] [ 6 fixed ]

Set the tens slide on the “SLIDER“ to [ 1 ] [ 1 blinking ] [ 6 fixed ]

Valid the tens press display [ 16 ] [ 16 ]

The time is confirmed and the cooking starts.

 To stop the cooking time:

Example for 13 minutes at power 7 :

Action Control panel Display

Zone selection press display [ 0 ] selected [ 0 ] and control light on

Select “Timer” press key [ 13 ] [ 13 ]

Deactivate the units slide on the “SLIDER“ to [ 0 ] [ 1 fixed ] [ 0 blinking ]

Valid the units press display [ 10 ] [ 1 blinking ] [ 0 fixed ]

Deactivate the tens slide on the “SLIDER“ to [ 0 ] [ 0 blinking ] [ 0 fixed ]

Valid the tens press display [ 00 ] [ 00 ]
