English

OPERATION

NOTE: The drill will not run unless the rotation selector is

pushed fully to the left or right.

Avoid running the drill at low speeds for extended periods

of time. Running at low speeds under constant usage

may cause the dr

cool the drill by running it without a load and at full speed.

INTERNAL SPINDLE LOCK

The internal spindle

control of chuck adjustments and bit changes . Squeezing

the body stops the chuc

bit changes and chuc

body and turn.

KEYLESS CHUCK

The drill has a keyless

chuck

lock allows

ill to become If this occurs , overheated.

k adjustments, squeeze the chuck

k from tur jaws ning. For

the user single-handed

chuck to tighten or release drill

bits in the chuck jaws. The arrows on the chuc k indicate

which direction to rotate the chuck body in order to LOCK

(tighten) or UNLOCK (release) the drill bit.

WARNING

Do not hold the chuck with one hand and use the

power of the drill to tighten the chuck jaws on the

drill bit. The chuck body could slip in y

or your hand could slip and come in contact with

the rotating drill bit. This could cause an accident

resulting in serious personal injury.

TWO-SPEED GEAR TRAIN (HI-LO)

The drill has a gear two-speed designed drilling for

or at LO (1) or HI (2) speeds. A slide s

located on top of the dr

speed. When using drill in the LO (1) speed range, speed

will decrease and unit will ha

When using dr

driving

train

ill to select either LO (1) or HI (2)

ill in the HI (2) speed range, speed will

increase and unit will ha

LO (1) speed for high power and torque applications and

HI (2) speed for fast drilling or driving applications.

See Figure 6.

ve less and torque . Use power

ve more and torque . power

witch is

our hand,

CAUTION:

Never change gears while the tool is r

Failure to obey this caution could result in serious

damage to the drill.

QUICK MODE SELECTOR

The Quick Mode Selector allows you to quickly switch

from drill mode to drive mode.

In general, mode should be used f

other duty applications mode should be

used for driving screws mode should be used

for impact drilling.

SELECTING DRIVE OR DRILL SETTING

See Figure

Using the char

the type of bit, fastener, and material you will be using.

■ Choose your APPLICATION

■ Choose the correct SPEED: (1/LOW or 2/HIGH)

■ Choose the correct MODE: (DRIVE, DRILL, OR

HAMMER)

. Hammer

5-6.

. Drive heavy

drill

t below, choose correct speed and mode

or dr illing and

unning.

1. APPLICATION 2. SPEED 3. MODE

• Lag screws up to 9.5 mm dia. by 38.1 mm long

• Hole saw up to 50.8 mm

• Spade bits up to 38.1 mm

• Drill bits up to 12.7 mm

• Drilling into metal

• Concrete screws

1/LOW

DRILL MODE

(TORQUE ADJUSMENT NOT ACTIVE)

2/HIGH

• Drill bits up to 6.4 mm

• Deck or wood screws up to 76.2 mm long

• Self tapping screws

1/LOW

DRIVE MODE

• Deck or wood screws up to 76.2 mm long

• Small screws or delicate work that requires more control

2/HIGH

• Masonry bit up to 12.7 mm

1/LOW

HAMMER MODE

(TORQUE ADJUSMENT NOT ACTIVE)

2/HIGH

See Figure 4.

See Figure 5.
