Hitachi DS18DSDLRW [16/148] English

English

6. How to select tightening torque and rotational speed

CAUTION:

 The selection examples shown in Table 5 should be

considered as general standard. As different types of

tightening screws and different materials to be

tightened are used in actual works proper adjustments

are naturally necessary.

 When using the driver drill with a machine screw at

HIGH (high speed), a screw may damage or a bit may

loose due to the tightning torque is too strong. Use

the driver drill at LOW (low speed) when using a

machine screw.

NOTE:

The use of the battery in a cold condition (below 0

degree Centigrade) can sometimes result in the

weakened tightening torque and reduced amount of

work. This, however, is a temporary phenomenon,

and returns to normal when the battery warms up.

7. Using the hook

The hook is used to hang up the power tool to your

waist belt while working.

CAUTION:

 When using the hook, hang up the power tool firmly

not to drop accidentally.

If the power tool is dropped, it may lead to an accident.

 When carrying the power tool with hooked to your

waist belt, do not fit any bit to the tip of power tool. If

the sharp bit such as drill is fitted to the power tool

when carrying it with hooked to your waist belt, you

will be injured.

 Install securely the hook. Unless the hook is securely

installed, it may cause an injury while using.

(1) Removing the hook.

Remove the screws fixing the hook with Phillips screw

driver. (Fig. 11)

(2)

Replacing the hook and tightening the screws.

Install securely the hook in the groove of power tool

and tighten the screws to fix the hook firmly. (Fig. 12)

8. About Remaining Battery Indicator

When pressing the remaining battery indicator switch,

the remaining battery indicator lamp lights and the

battery remaining power can be checked. (Fig.13)

When releasing your finger from the remaining

battery indicator switch, the remaining battery

indicator lamp goes off. The Table 6 shows the state

of remaining battery indicator lamp and the battery

remaining power.

Work Suggestions

Brick <DV14DSDL / DV18DSDL>

Wood

Drilling

Steel

Use for drilling purpose.

Aluminum

Machine screw Use the bit or socket matching the screw diameter.

Driving

Wood screw Use after drilling a pilot hole.

Table 4

Use

Clutch dial Position

Rotating speed selection (Position of the shift knob)

LOW (Low speed) HIGH (High speed)

Machine screw 1 – 22

For 6 mm or smaller

diameter screws.

Driving

Wood screw 1 –

For 8 mm or smaller nominal

diameter screws.

For 14 mm or smaller

Brick diameters. (DV14DSDL)

For 16 mm or smaller

diameters. (DV18DSDL)

Drilling

Wood

For 50 mm or smaller

diameters.

(DS14DSDL / DV14DSDL)

For 65 mm or smaller diameters.

(DS18DSDL / DV18DSDL)

Metal

For 4 mm or smaller

diameter screws.

For 4.8 mm or smaller

nominal diameter screws.

For 10 mm or smaller

diameters. (DV14DSDL)

For 12 mm or smaller

diameters. (DV18DSDL)

For 24 mm or smaller diameters.

(DS14DSDL / DV14DSDL)

For 27 mm or smaller diameters.

(DS18DSDL / DV18DSDL)

For drilling with a metal

working drill bit.

Table 5

State of lamp Battery Remaining Power

The battery remaining power

is enough.

The battery remaining power

is a half.

The battery remaining power

is nearly empty.

Re-charge the battery soonest

possible.

Table 6
