Inspect sandpaper before installing. DO NOT use if

broken of defective.

INSTALLING ADHESIVE (HOOK& LOOP)

SANDPAPER (13)

OPERATION

■ Unplug the sander.

■ If replacing ahesive sandpaper, remove old

sandpaper by peeling it off cushion.

NOTE: Sand for a few minutes to soften the adhesive

backing before attempting to remove old sandpaper.

■ Carefully peel adhesive backing from new 1/2 sheet

sandpaper.

■ Position sandpaper, making sure front edge of

sandpaper is aligned with front edge of the cushion,

then carefully press sticky side of sandpaper on

cushion.

■ If the new sandpaper have a dust hole, then align

holes in paper with holes in cushion, then carefully

press fuzzy side of sandpaper against cushion as

tightly as possible.

INSTALLING NON-ADHESIVE SANDPAPER (9)

■ Lifting up the handle (11), and observing the

sandpaper clamp (12) be lifting up also.

■ Insert end of new 1/2 sheet sandpaper approximately

1/2 in. (12.7mm) under the paper clamp.

Note: 1/2 in. clamping of sandpaper is necessary for

multisheet stacking of paper.

■ Release down the handle and apply clamp downward

pressure to conform sandpaper to platen.

■ Wrap sandpaper around cushion. Lifting up another

handle on opposite end of sander and insert loose

end of sandpaper under clamp also. Fit sandpaper

tight against with cushion.

■ Release down the handle.

■ Multi-sheet of sandpaper can be installed at one time

for convenience.

PAPER PUNCH (Fig. 6)

A paper punch template has been supplied with your

sander for aligning and punching holes in sandpaper. The

punched holes must align with the holes in the sander

cushion.

■ Install sandpaper on your sander.

■ Align sander cushion over the paper punch.

■ Push down on sander

SANDPAPER SELECTION

Selecting the correct size grit and type sandpaper is an

extremely important step in achieving a high quality

sanded finish. Aluminum oxide, silicon carbide, and other

synthetic abrasives are best for power sanding. Natural

abrasives, such as flint and garnet are too soft for

economical use in power sanding.

In general, coarse grit will remove the most material and

finer grit will produce the best finish in all sanding

operations. The condition of the surface to be sanded will

determine which grit will do the job. If the surface is

rough, start with a coarse grit and sand until the surface

is uniform. Medium grit may then be used to remove

scratches left by the coarser grit and finer grit used for

finishing of the surface. Always continue sanding with

each grit until surface is uniform.

Note: DO NOT use sander without sandpaper. Doing so

will damage the cushion.

PREPARING FOR OPERATION

CAUTION

Be careful not to let your hand completely cover

air vents.

SANDING (Fig. 1)

WARNING

Unsecured work could be thrown towards the

operator causing injury.

Hold your sander in front and away from you, keeping it

clear of the workpiece. Start your sander by pressing the

switch button to "ON" position and letting the motor build

to its maximum speed. Gradually lower your sander on

the work with a slight forward movement. Move it slowly

using forward and backward strokes.

DO NOT FORCE. The weight of the unit supplies adequate

pressure, so let the sandpaper and sander do the work.

Applying additional pressure only slows the motor, rapidly

wears sandpaper and greatly reduces sander speed.

Excessive pressure will overload the motor causing

possible damage from motor overheating and can result in

inferior work.

Any finish or resin on wood may soften from the frictional

heat. Do not allow sanding on one spot too long as the

sander's rapid action may remove too much material,

making the surface uneven.

WARNING

Do not wear loose clothing or jewelry when

operating sander. They could get caught in
