-20-
[For DV 13VSS, DV 16VSS]
(1) Wiring of reversing switch
(2) Wiring of speed control switch
Cord: Black or BrownCord: White or Blue
21
2a
2b 1a
Stator: Red
Stator: Gray
Earth Terminal <46>
Noise Suppressor
Stator: Black
Stator: White
35
64
Choke Coil or Lead Wire: Blue
Choke Coil or Lead Wire: Brown
