Hitachi DV16VSSNA [31/41] Description remarks
![Hitachi DV16VSSNA [31/41] Description remarks](/views2/1366984/page31/bg1f.png)
PART
S
DV 13VSS
DESCRIPTION REMARKS
1 995-344 FLAT HD. SCREW (A) (LEFT HAND) M6 X 25 1
* 2 987-576 CHUCK WRENCH FOR 13VLB-D, 13VLR-D 1
* 3 DRILL CHUCK 13VLRC-D 1
INCLUD. 2 SUPPLIED WITH ITEM NO.601
* 3 322-625 DRILL CHUCK 13VLRJ-N (W/O CHUCK WRENCH) 1
4 948-001 RETAINING RING FOR D32 HOLE 1
5 971-654 DUST SEAL 1
6 331-522 SPINDLE 1
7 322-514 SPRING 1
8 330-682 DISTANCE RING 1
9 600-2VV BALL BEARING 6002VVCMPS2L 1
10 939-544 RETAINING RING FOR D15 SHAFT (10 PCS.) 1
11 322-657
TAPPING SCREW (W/FLANGE) D4 X 60 (BLACK) 2
12 330-681 GEAR COVER 1
13 330-683 GEAR 1
14 959-150 STEEL BALL D6.35 (10 PCS.) 1
15 301-815 TAPPING SCREW (W/FLANGE) D4 X 45 1
16 330-680 TAPPING SCREW (W/SP. WASHER) D4 X 20 2
17 330-677 RATCHET 1
18 330-678 BUSHING 1
19 330-679 BOLT M3 4
20 330-676 CHANGE PLATE 1
21 330-675 INNER COVER 1
22 322-510 CHANGE LEVER 1
23 323-096 FELT PACKING 1
24 330-674 WASHER (A) 1
25 608-DDM BALL BEARING 608DDC2PS2L 1
* 26 360-864C ARMATURE 110V 1
* 26 360-864U ARMATURE ASS'Y 120V 1 INCLUD. 25, 30
* 26 360-864E ARMATURE 220V 1
* 26 360-864G ARMATURE 230V-240V 1
27 330-673 FAN GUIDE 1
28 991-031 TAPPING SCREW D4 X 45 2
* 29 340-743C STATOR 110V 1
* 29 340-743D STATOR 120V 1
* 29 340-743E STATOR 220V 1
* 29 340-743G STATOR 230V-240V 1
30 608-VVM BALL BEARING 608VVC2PS2L 1
31 330-715 HANDLE COVER 1
32 301-653
TAPPING SCREW (W/FLANGE) D4 X 20 (BLACK) 3
33 330-719 HITACHI LABEL 1
34 330-714 HOUSING 1
35 NAME PLATE 1
36 955-203 BRUSH HOLDER 2
37 999-041 CARBON BRUSH (1 PAIR) 2
* 38 981-373 TUBE (D) 2 FOR CORD
39 937-631 CORD CLIP 1
40 984-750 TAPPING SCREW (W/FLANGE) D4 X 16 2
* 41 330-716 SWITCH 1
* 41 330-684 SWITCH 1
FOR GBR (110V), USA, CAN, MEX, VEN, TPE
* 42 330-717 INTERNAL WIRE (BROWN) 1 FOR USA, CAN, VEN, TPE, SYR, INA, HKG, KUW, IND, THA, SIN
- 2 - 05 - 09
*ALTERNATIVE PARTS
ITEM
NO.
NO.
USED
CODE NO.
