4
English
*Be sure to check the nameplate on product as it is subject to change by areas.
SPECIFICATIONS
Model SV13YA SV13YB
Voltage (by areas)* (110 V, 120 V, 220 V, 230 V, 240 V)
Power Input 230 W*
No-load speed 7000 – 12000 min
–1
12000 min
–1
Sanding pad size (Outer diameter) 125 mm
Sanding paper size (Outer diameter) 125 mm
Weight (without cord) 1.4 kg
STANDARD ACCESSORIES
䡬 Sanding paper ............................................................ 1
䡬 Dust bag ...................................................................... 1
Standard accessories are subject to change without notice.
OPTIONAL ACCESSORIES (sold separately)
1. Sanding paper
Grain: AA40, AA60, AA80, AA120, AA180, AA240,
AA320, AA400
2. Polyester buff
Optional accessories are subject to change without notice.
APPLICATIONS
䡬 Roughing or finishing of woodwork and metal surfaces.
䡬 Preliminary sanding of woodwork and metal surfaces
before painting.
䡬 Paint removal.
䡬 Rust removal.
PRIOR TO OPERATION
1. Power source
Ensure that the power source to be utilized conforms
to the power requirements specified on the product
nameplate.
2. Power switch
Ensure that the power switch is in the OFF positon. If
the plug is connected to a receptacle while the power
switch is in the ON position, the power tool will start
operating immediately, which could cause a serious
accident.
3. Extension cord
When the work area is removed from the power
source, use an extension cord of sufficient thickness
and rated capacity. The extension cord should be
kept as short as practicable.
4. Installing the sanding paper
Since the attachment is a hook-and-loop type, the
sanding paper can be installed easily by just press-
ing it onto the pad. When installing the sanding
paper, in order to match it to the holes in the pad,
gently fold it along the axis of two holes as shown
in Fig. 1.
Next, use the holes along the fold as a guide to
match the sanding paper and the pad. Finally, press
the entire sanding paper uniformly onto the pad.
5. Attaching and Removing the Dust Bag
(1) Attaching the Dust Bag
As shown in Fig. 2, hold the dust gate and push it in
the direction of Arrow A to attach it to the dust outlet.
(2) Removing the Dust Bag
As shown in Fig. 2, hold the dust gate and pull it in
the direction of Arrow B to remove it from the dust
outlet.
CAUTION
Prior to the sanding operation, make sure the material
of surface you are going to sand.
If the surface under sanding operation is expected to
generate harmful / toxic dusts such as lead painted
surface, make sure the dust bag or appropriate dust
extraction system is connected with dust outlet tightly.
Wear the dust mask additionally, if available.
Do not inhale or touch the harmful / toxic dusts
generated in sanding operation, the dust can
endanger the health of yourself and bystanders.
6. Adjustment of speed (SV13YA only)
The SV13YA is equipped with the electric control
circuit which enables non-step speed control. To
adjust the speed, turn the dial shown in Fig. 3.
When the dial is set to “1”, the sander operates
at the minimum speed (7000 min
–1
). When the dial
set to “6”, the sander operates at the maximum
speed (12000 min
–1
). Adjust the speed according to
the material to be cut and working efficiency.
