9
Original instructions
EN
is connected to a receptacle while the power
switch is in the ON position, the power tool
will start operating immediately, which could
cause a serious accident.
Make sure that the cord and the plug are in
order. If the replacement of the supply cord is
necessary, this has to be done by the manu-
facturer or his agent in order to avoid a safety
hazard.
WARNING: Always switch off and un-
plug the power tool prior to any adjustment,
servicing or maintenance.
Make sure the grinding wheel diameter and
thickness do not exceed the values specied
on the name plate. The peripheral speed in-
dicated on the wheel must not be less than
80 m/s. The wheels must be stored according
the recommendations of the manufacturer.
In case the work area is remote from the pow-
er source, use as short as practicable exten-
sion cord with proper cross-section.
Check that the auxiliary handle is properly
mounted and reliably tightened.
SWITCHING ON - SWITCHING Off
The angle grinder is secured against uninten-
tional switching on.
Switching on: First push forward the auxiliary
button 8 positioned at the bottom of the main
handle, then press ON/OFF switch 7. For
continuous operation switch 7 can be locked.
In this case while holding switch 7, press but-
ton 8 and then release switch 7.
Switching off: Release switch 7; in case the
switch is locked, rst press and then release
that switch.
WHEEL GUARD
WARNING: The wheel guard 3.1 for
grinding wheel or the wheel guard 3.2 for
cutting wheel (for grinding wheel 2.1 or cut-
ting wheel 2.2 accordingly) must always be
mounted on the machine!
WARNING: Before performing the fol-
lowing operations, switch off and unplug the
machine.
Mounting the wheel guard (fig. 1)
- Rotate the black plastic ring (Fig. 2a), so
that the crevice S of the ring coincides with the
groove for the tooth of the xing lever L.
- Place the wheel guard in non-operating
position (Fig.2a) so that the four teeth coin-
cide with the four grooves in the bearing seat
(Fig.2b).
- Press the fastening lever L (g.3) to re-
lease it.
- Press the wheel guard down and rotate it
in the necessary operating position (Fig.4).
- Release the fastening lever L to a stable
position in which the wheel guard is xed (the
xing lever tooth enters into one of the guard
grooves).
Rotating the wheel guard in a new operat¬ing
position
- Press the fastening lever L (Fig.3) to re-
lease it.
- Rotate the wheel guard to the necessary
operating position.
- Release the fastening lever L to a stable
position in which the wheel guard is xed (the
xing lever tooth enters into one of the guard
grooves).
Removing the wheel guard
- Press the fastening lever L (Fig.3) to re-
lease it.
- Rotate the wheel guard in non-operating
position (Fig.2a) so that the four teeth coin-
cide with the four grooves in the bearing seat
(Fig.2b).
- Remove the wheel guard.
GRINDING WHEEL REPLACEMENT
WARNING: Before performing the fol-
lowing operations, switch off and unplug the
machine.
Secure spindle 1 by pressing the spindle lock
button 9 on the gear case.
WARNING: Never press button 9
while the spindle is still rotating!
With this button depressed rotate the wheel
in direction opposite to the arrow marked on
the wheel guard 3 until it has profoundly gone
deeper. Unscrew xing ange 5 by a special
wrench. Place the new wheel on the sup-
