ASSEMBLY PROCEDURES
Drive shaft to engine (Fig. 1)
Loosen tube locking bolt (1) about ten turns so that the bolt point will
not obstruct drive shaft tube to be inserted. When inserting drive
shaft tube, hold the tube locking bolt outward preventing inside
fi tting from obstructing as well.
Some models may come with the drive shaft already installed.
NOTE
When it is hard to insert drive shaft up to the marked position on
the drive shaft tube, turn drive shaft by the cutter mounting end
clockwise or counter-clockwise. Tighten tube locking bolt lining
up the hole in the shaft tube. Then tighten clamp bolt securely
(1).
Installation of handle
Remove the handle bracket (2) from the assembly. (Fig. 2)
Place the handles and attach the handle bracket with four bolts
lightly. Adjust to appropriate position. Then attach it fi rmly with the
bolts.
Attach the protection tube to the drive shaft or handle using cord
clamps (3). (Fig. 3)
NOTE
If the protection tube is set apart from the handle or pipe, it will
be caught by something during operation and it may cause
serious injury. Do not set the protection tube apart from the
handle or pipe.
Throttle wire / stop cord
Remove air cleaner cover. (Fig. 4)
Connect stop cords. (Fig. 5)
Insert the stay (4) under the nut (5) screwed onto the outer end of
the throttle wire (6) and connect the end of the throttle wire (7) to the
carburetor (8). Then tighten the nut (5) to secure the throttle wire to
the stay (4). (Fig. 6)
NOTE
Check that the carburetor throttle returns to the idle position
and also that it can be opened wide by operating the throttle
lever.
Cover throttle wire and stop cords together with protective tube
provided up to air cleaner cover. (Fig. 7)
Some models may come with the drive shaft already installed.
Installation of blade guard (Fig. 8)
The guard bracket already mounted to the drive shaft tube.
Install the blade guard on drive shaft tube against angle
transmission (9). Tighten the guard bracket fi rmly so that the blade
guard does not swing or move down during operation.
CAUTION
The blade guard must be in place during operation.
If the blade guard is not in place, there is a possibility of serious
injury.
Blade guards are equipped with sharp line limiter. Be careful with
handling it.
NOTE
○ When attaching the guard extension to the blade guard, the
sharp line limiter must be removed from the blade guard.
○ To remove the guard extension, refer to the drawings. Wear
gloves as the extension has a sharp line limiter, then push the
two square tabs on the guard one by one in order after removed
the screw. (Fig.
10)
Installation of cutting blade (Fig. 11)
When installing a cutting blade, make sure that there are no cracks
or any damage in it and that the cutting edges are facing the correct
direction.
Align the notch hole of the cutter holder with the hole on the gear
case (Top the gear case) and insert the Allen wrench to stop
turning. Turn the fi xing nut clockwise and remove the fi xing nut,
protection cover, cutter holder cap, and toothed lock washers.
The installation of the cutting blade is as follows: insert the Allen
wrench into the notch hole of the cutter holder and the hole on
the gear case. Then, install the cutting blade (check the installing
direction, as referring to Fig. 13), the cutter holder cap, protection
cover and toothed lock washers onto the cutter holder in this order.
Finally, tighten the fi xing nut securely by turning counterclockwise
with the Combi box spanner. (Fig. 11)
CAUTION
○ When installing the cutting blade, set its center hole to the
convex part of the cutter holder and hold it with the concave
surface of the cutter holder cap. Then, tighten the fi xing nut to
prevent the cutting blade from being eccentric. (Fig. 11)
After installing the cutting blade, be sure to remove the Allen
wrench and Combi box spanner.
○ Before operation, make sure the blade has been properly
installed.
○ Before operation, check the cutter holder cap under the cutting
blade for wear or cracks. If any damage or wear is found,
replace it, as it is an article of consumption.
NOTE
The blade must be retained with a new cotter pin each time
installed. (Fig. 11)
Installation of nylon head
Attach cutter holder (10) to the gear case. Insert an Allen wrench
into the hole in the gear case to attach winding protector (11) and
attach nylon head (12) by turning it clockwise.
NOTE
Since cutter holder cap is not used here, keep it for next metal
blade use.
OPERATING PROCEDURES
Fuel (Fig. 15)
WARNING
○ The brush cutter is equipped with a two-stroke engine. Always
run the engine on fuel, which is mixed with oil.
Provide good ventilation, when fueling or handling fuel.
○ Fuel is highly fl ammable and toxic and can result in serious
injury if it is inhaled or comes into contact with your skin. Always
handle fuel with care. Always have good ventilation when
handling fuel inside building.
Fuel
○ Always use branded 89 octane unleaded gasoline.
○ Use genuine two-cycle oil or use a mix between 25:1 to 50:1,
please consult the oil bottle for the ratio or Hitachi dealer.
○ If genuine oil is not available, use an anti-oxidant added quality
oil expressly labeled for air-cooled 2-cycle engine use (JASO
FC GRADE OIL or ISO EGC GRADE). Do not use BIA or TCW
(2-stroke water-cooling type) mixed oil.
○ Never use multi-grade oil (10 W/30) or waste oil.
○ Always mix fuel and oil in a separate clean container.
Always start by fi ling half the amount of fuel, which is to be used.
Then add the whole amount of oil. Mix (shake) the fuel mixture. Add
the remaining amount of fuel.
Mix (shake) the fuel-mix thoroughly before fi lling the fuel tank.
Fueling
WARNING
○ Always shut off the engine before refueling.
○ Slowly open the fuel tank, when fi lling up with fuel, so that
possible over-pressure disappears.
○ Tighten the fuel cap carefully, after fueling.
