7. SPECIFICATIONS

Avatar ampliﬁers are high-quality and technically perfect products. The problems often arise due to improper use, faulty

connection of components or lack of power supply of the on-board network.

1) The ampliﬁer does not turn on.

Problem solution: Check all the contacts and the presence of 10-15 V at the ampliﬁer terminals. Check whether the control

input of the ampliﬁer "REM" receives the positive potential of 12 V.

2) Power turns on, but goes into protection (security indicator lights up)

Problem solution: Check if there is a short circuit (fault) on the ampliﬁer output which is connected to the speakers or

subwoofers. Make sure that commutation of the voice coils of the subwoofer is correct. The rated impedance of the voice coils

should not be lower than the permissible rated load impedance of the ampliﬁer. Check the supply voltage of the ampliﬁer. It must

be within the range of 10-15 V.

3) The ampliﬁer turns on but at a high volume it goes to protection. Problem solution: The ampliﬁer may lack power. Make sure

that the rated current of the alternator and the battery capacity is enough to power this ampliﬁer.

Check the ampliﬁer for overheating. Check the load impedance.

4) The ampliﬁer is turned on, but there is no sound from the speakers or subwoofer.

Problem solution: Check the connection of the ampliﬁer, the integrity of the interconnecting cable, HU, the speaker or the

subwoofer.

8. POSSIBLE FAULTS AND THEIR SOLUTIONS

Power RMS 4 Ohm*

Power RMS 2 Ohm*

Low pass ﬁlter

Frequency response

Input sensitivity

Signal to noise ratio

Model

Working voltage

200 W х 1 400 W х 1 600 W х 1 900 W х 1

350 W х 1 600 W х 1 1000 W х 1 1350 W х 1

8 Hz - 180 Hz 8 Hz - 180 Hz 8 Hz - 180 Hz 8 Hz - 180 Hz

0.2 V - 5 V 0.2 V - 5 V 0.2 V - 5 V 0.2 V - 5 V

≥ 70 ≥ 70 ≥ 70 ≥ 70

ATU-500.1D ATU-1000.1D ATU-1500.1D ATU-2000.1D

10 V - 15 V 10 V - 15 V 10 V - 15 V 10 V - 15 V

Subsonic 10 Hz - 50 Hz 10 Hz - 50 Hz 10 Hz - 50 Hz 10 Hz - 50 Hz

40 Hz - 180 Hz 40 Hz - 180 Hz 40 Hz - 180 Hz 40 Hz - 180 Hz

Size (WхLхH mm)

The minimum permissible load impedance

220 x 185 х 59 330 x 185 х 59 342 x 185 х 59 416 x 185 х 59

1 Ohm 1 Ohm 1 Ohm 1 Ohm

12 dB/Oct 12 dB/Oct 12 dB/Oct 12 dB/OctCrossover

*RMS Power at 14.4 V, THD 1%

The minimum permissible load impedance in bridged connection 2 Ohm 2 Ohm 2 Ohm 2 Ohm

Power RMS 1 Ohm* 500 W х 1 1000 W х 1 1500 W х 1 2000 W х 1

Class D D D D

0 - 12 dB 0 - 12 dB 0 - 12 dB 0 - 12 dBBass level adjustment

Size (WхLхH inch) 8.66 x 7.28 х 2.32 12.99 x 7.28 х 2.32 13.46 x 7.28 х 2.32 16.38 x 7.28 х 2.32

30 - 80 Hz 30 - 80 Hz 30 - 80 Hz 30 - 80 HzBass frequency adjustment

1. Ampliﬁer – 1 pcs.

2. Owner's Manual – 1 pcs.

3. Warranty card – 1 pcs.

4. Mounting Kit – 1 pcs.

5. Remote control – 1 pcs.

9. BOX CONTENT
