Installation Manual of Network BoX Camera
5
5 RESET: Reset all parameters to factory default settings
6 10M / 100M self-adaptive Ethernet interface
7 Power supply
8 Power LED indicator, which turns red when power is applied to the unit
9 SD card slot
10 Audio input interface
11 Audio output interface
12 Ground
NOTE:
When the camera is power up, press the ‘RESET’ button for about 10 seconds, then all
parameters, including user name, password, IP address, port number, etc., will be
reset to the factory default settings.
2.1.3 Camera Connection
Connection of DS-2CD886BF-E and DS-2CD876BF:
Connection of DS-2CD886MF-E and DS-2CD876MF:
