Axis P1346 [4/66] Product description
![Axis P1347 [4/66] Product description](/views2/1372486/page4/bg4.png)
4
AXIS P1346/-E/AXIS P1347/-E - Product Description
Product Description
This manual applies to the following products:
• AXIS P1346 Network Camera
• AXIS P1346-E Network Camera
• AXIS P1347 Network Camera
• AXIS P1347-E Network Camera
The information in this manual applies to all models except where otherwise indicated.
Key features
• Excellent video quality including HDTV
AXIS P1346/-E/AXIS P1347/-E supports wide dynamic range and includes day/night functionality with an automati-
cally controlled IR filter, adapting to both daylight and dark lighting conditions. While AXIS P1346/-E offers superb
image quality in 3MP resolution, AXIS P1347/-E offers 5 MP resolution. All these cameras offer HDTV streaming in
1080p at 30 fps.
• P-Iris control
AXIS P1346/-E/AXIS P1347/-E supports the unique P-Iris control, which allows the camera to precisely control the
exact position of the iris. This gives an iris opening optimized for depth of field, lens resolution and light inlet, result-
ing in superb image quality with optimal sharpness. The P-Iris uses the same type of connector and cable as the tradi-
tional DC-iris control, which is also supported by AXIS P1346/-E/AXIS P1347/-E for backward compatibility.
• Multiple H.264 and Motion JPEG video streams
AXIS P1346/-E/AXIS P1347/-E can provide several independent H.264 streams for different quality needs and band-
width constraints; e.g. live viewing in highest quality and full frame rate, and simultaneously delivering a video stream
configured for optimized storage, at a lower resolution or frame rate, or a higher compression level. Motion JPEG
images can be provided simultaneously for easy extraction of high-quality still images.
• Digital PTZ and multi-view streaming
AXIS P1346/-E/AXIS P1347/-E supports digital PTZ and multi-view streaming allowing up to eight view areas cropped
from the full view to be streamed simultaneously for viewing or recording. The camera allows panning and tilting of
the cropped view areas as well as digital zoom in.
• Easy installation with focus assistant, remote back focus and pixel counter
The focus assistant and remote back focus features make AXIS P1346/-E/AXIS P1347/-E easy to install. At first the
focus assistant facilitates approximate focusing of the lens which indicates focus by flashing the camera’s front LED.
Then the remote back focus feature of AXIS P1346/-E/AXIS P1347/-E is conveniently used for automatic focus
fine-tuning. During focusing, the pixel counter helps to ensure that the image size and resolution is optimized and
that specific requirements, for example for face recognition, are fulfilled.
• Power over Ethernet
AXIS P1346/-E/AXIS P1347/-E supports Power over Ethernet (IEEE 802.3af) reducing installation costs by eliminating
the need for power cables. AXIS P1346-E/AXIS P1347-E can alternatively be powered by High Power over Ethernet.
AXIS P1346 /AXIS P1347 can alternatively be powered by 8-20 V DC.
• Local storage
AXIS P1346/-E/AXIS P1347/-E offers an SD/SDHC memory card slot for local storage of video.
• Two-way audio
Two-way audio support allows remote users to listen in on an area and communicate with visitors or intruders.
• Robust design
AXIS P1346/-E/AXIS P1347/-E with its robust, metal casing in a box design is perfect for deterrence.
• Intelligent video capabilities
AXIS P1346/-E/AXIS P1347/-E includes intelligent capabilities such as video motion detection, audio detection and
detection of camera tampering attempts like blocking, spray-painting or defocusing. The camera also provides capac-
ity for third party analytics modules.
• Outdoor-ready (AXIS P1346-E/AXIS P1347-E)
AXIS P1346-E/AXIS P1347-E is designed for quick and easy installation in demanding indoor and outdoor environ-
ments. There is no need to purchase and mount a separate outdoor housing. It eliminates the cost and complexity of
pre-mounting a camera in an enclosure and minimizes the risk of incorrect mounting, and helps to ensure optimal
camera performance.
