AXIS P1346/-E/AXIS P1347/-E - System Options

Traps for SNMP v1/v2

Traps are used by the camera to send messages to a management system for important events or status changes.

If Enable traps is selected, enter the email address where the trap message is to be sent as well as the Trap community that

should receive the message.

There are four types of traps available for the network camera.

• Cold start

•Warm start

•Link up

• Authentication failed

SNMP v3

SNMP V3 - provides encryption and secure passwords. HTTPS must be enabled. To use traps with SNMP v3 an SNMP v3

management application is required.

If the Enable SNMP v3 option is enabled, provide the Initial user password. Note that the initial password is activated only

when HTTPS is enabled and can only be set once.

If HTTPS is enabled, SNMP v1 and SNMP v2c should be disabled.

When SNMP configuration is ready, click Save to use the new settings or Reset to return to the default values.

UPnP™

The network camera includes support for UPnP™. UPnP™ is enabled by default, and the network camera then is automatically

detected by operating systems and clients that support this protocol.

RTP/H.264

These settings are the port range, IP address, port number (video and audio), and Time-To-Live value to use for the video

stream(s) in multicast H.264 format. Only certain IP addresses and port numbers should be used for multicast streams. For

more information, please see the online help.

Bonjour

The network camera includes support for Bonjour. When enabled, the camera is automatically detected by operating systems

and clients that support this protocol.

Storage - Disk Management

Disk Management is used to setup and manage local storage devices. Local storage can be used to save video streams from

triggered, scheduled or continuous recordings. For information on how to use the local storage with Triggered and Scheduled

Event Type Setup and Continuous Recordings see the online help .

Storage Device

Once a formatted SD card has been inserted in the SD memory card slot, it is automatically mounted and information such as

the available space and the size of the storage device is shown. The disk is full when there is less than 1000KB of space left on

the memory card.

Disks are normally preformatted when purchased, if a SD Card needs to be formatted click the Format button to format the

disk. Any previous data stored on the disk will be lost. Mounting is done automatically when a new memory card is inserted, or

when the system boots. The only time you need to do a manual mount, is when you have executed an unmount command and

the memory card has not been ejected and reinserted.
