14 DXZ758RMC
280-8170-00
English
Basic Operations
Adjusting the bass (Gain,
Frequency, Q-curve)
This adjustment can only be performed when
the ADF (Anti Distortion Filter) is set to “ADF
OFF”.
1. Press the [A-M] button and select “BASS
GAIN”.
2. Turn the [ROTARY] knob to adjust the bass.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +8)
3. Move the [a]/[d] lever to select “BASS
FREQ”.
Turn the [ROTARY] knob to select the fre-
quency.
∗ The factory default setting is “50”. (Adjustment
50/80/120 Hz)
4. Move the [a]/[d] lever to select “BASS Q”.
Turn the [ROTARY] knob to select the Q-
curve.
∗ The factory default setting is “1”. (Adjustment
1/1.25/1.5/2)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble (Gain,
Frequency)
This adjustment can only be performed when
the ADF (Anti Distortion Filter) is set to “ADF
OFF”.
1. Press the [A-M] button and select “TREBLE
GAIN”.
2. Turn the [ROTARY] knob to adjust the treble.
∗ The factory default setting is “0”. (Adjustment
range: –6 to +6)
3. Move the [a]/[d] lever to select
“TREBLE FREQ”.
Turn the [ROTARY] knob to select the fre-
quency.
∗ The factory default setting is “12k”. (Adjust-
ment 8 kHz/12 kHz)
4. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the balance
1. Press the [A-M] button and select “BAL-
ANCE”.
2. Turn the [ROTARY] knob to adjust the bal-
ance of the left and right speakers.
∗ The factory default setting is “0”. (Adjustment
range: L13 to R13)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the fader
1. Press the [A-M] button and select “FADER”.
2. Turn the [ROTARY] knob to adjust the bal-
ance of the front and rear speakers.
∗ The factory default setting is “0”. (Adjustment
range: F12 to R12)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
