280-8170-00
DXZ758RMC 41
English
10. SPECIFICATIONS
Radio section
Tuning System: PLL synthesizer tuner
Receiving Frequencies:
FM : 87.5 to 108 MHz (0.05 MHz steps)
MW : 531 to 1602 kHz (9 kHz steps)
LW : 153 to 279 kHz (3 kHz steps)
CD player
System: Compact disc digital audio system
Frequency Response: 5 Hz to 20 kHz (± 1 dB)
Signal to Noise Ratio: 100 dB (1 kHz) IHFA
Dynamic Range: 95 dB (1 kHz)
Distortion: 0.01%
MC mode
HQ:
Approximately 265 minutes, 66 tracks
(4 minutes for each)
LP:
Approximately 353 minutes, 88 tracks
(4 minutes for each)
General
Output Power: 4 ✕ 31 W (DIN 45324, +B=14.4V)
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable),
negative ground
Power Consumption: Less than 15 A
Speaker Impedance: 4 Ω (4 to 8 Ω allowable)
Auto Antenna Rated Current: 500 mA or less
Weight / Main unit:
1.6 kg
Weight / Remote control unit:
40 g (including battery)
Dimensions / Main unit:
178 (W) ✕ 50 (H) ✕ 155 (D) mm
Dimensions / Remote control unit:
44 (W) ✕ 113 (H) ✕ 13 (D) mm
Note:
• Specifications and design are subject to change without notice for further improvement.
