Clarion DXZ758RMC [28/42] English
![Clarion DXZ758RMC [28/42] English](/views2/1003731/page28/bg1c.png)
28 DXZ758RMC
280-8170-00
English
Common Operations
Adjusting the auxiliary input
sensitivity
Adjust the auxiliary sensitivity when the audio
from an external device is difficult to hear even
after adjusting the volume.
∗ The factory default setting is “MID”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select
“AUX SENS”.
3. Turn the [ROTARY] knob to select from
“LOW”, “MID” or “HIGH”.
4. Press the [ADJ] button to return to the previ-
ous mode.
Setting the car speaker output for the
cellular phone (Optional TEL-002)
∗ The factory default setting is “RIGHT”.
∗ To output the telephone calls, set the cellular phone
interrupt to ON.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “TEL-
SPEAKER”.
3. Turn the [ROTARY] knob to select “RIGHT”
or “LEFT”.
● RIGHT:
Telephone calls can be heard on the front
right speaker connected to this unit.
● LEFT:
Telephone calls can be heard on the front left
speaker connected to this unit.
4. Press the [ADJ] button to return to the previ-
ous mode.
Cellular phone interrupt setting
If you connect this unit and your cellular phone
with a separately sold unit (TEL-002), you can
listen to your telephone calls on your car speak-
ers.
∗ The factory default setting is “OFF”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select
“TEL-SWITCH”.
3. Turn the [ROTARY] knob to select the set-
ting. Each time you turn the [ROTARY] knob,
the setting changes in the following order:
OFF ➜ ON ➜ MUTE ➜ OFF...
Setting the low pass filter
∗ The factory default setting is “THROUGH”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select
“SUB-W LPF”.
3. Turn the [ROTARY] knob to select the set-
ting. Each time you turn the [ROTARY] knob,
the setting changes in the following order:
THROUGH ➜ 50Hz ➜ 80Hz ➜ 120Hz
4. Press the [ADJ] button to return to the previ-
ous mode.
Setting the amplifier bypass circuit
∗ The factory default setting is “OFF”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “AMP
CANCEL”.
3. Turn the [ROTARY] knob to select “ON” or
“OFF”.
● ON:
Uses with connected AMP.
● OFF:
Uses with inside AMP.
4. Press the [ADJ] button to return to the previ-
ous mode.
Selecting AUX/TEL
You can listen to sounds and music from exter-
nal devices or your telephone calls from the
speakers when connected to this unit.
When TEL INT or External device is connected to
this unit, you can select TEL mode or AUX mode.
∗ The factory default setting is “AUX”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [a]/[d] lever to select “AUX/TEL”.
3. Turn the [ROTARY] knob to select “AUX” or
“TEL”.
● AUX :
AUX/TEL input cable is for external Audio in-
put.
● TEL :
AUX/TEL input cable is for cellular phone au-
dio input.
4. Press the [ADJ] button to return to the previ-
ous mode.
