Kenwood KMM-104GY [18/40] Installation connection

14

ENGLISH

Data Size: B6L (182 mm x 128 mm)

Book Size: B6L (182 mm x 128 mm)

REFERENCES

Change the display information

Each time you press

DISP

, the display information changes.

•

If the information is unavailable or not recorded, “NO TEXT”, “NO INFO”, or other information (eg. station name,

RADIO Frequency

Radio text+ (R.TEXT+)

Song title (Date/Clock)

Frequency (Date/Clock) (back to the

(back to the beginning)

File name (Date/Clock)

(back to the

iPod or

ANDROID

[MODE OFF]

/

is

( 8):

•

The unit can only be used with a 12V DC power supply, negative ground.

•

Disconnect the battery’s negative terminal before wiring and mounting.

•

Do not connect Battery wire (yellow) and Ignition wire (red) to the car

chassis or Ground wire (black) to prevent a short circuit.

–

Secure the wires with cable clamps and wrap vinyl tape around the

wires that come into contact with metal parts to protect the wires.

•

For safety’s sake, leave wiring and mounting to professionals. Consult the

car audio dealer.

•

Install this unit in the console of your vehicle. Do not touch the metal

parts of this unit during and shortly after use of the unit. Metal parts such

If your vehicle wiring harness does not have the ignition terminal,

connect Ignition wire (red) to the terminal on the vehicle’s fuse box which

provides 12V DC power supply and is turned on and off by the ignition

key.

•

Keep all cables away from heat dissipate metal parts.

•

After the unit is installed, check whether the brake lamps, blinkers,

wipers, etc. on the car are working properly.

•
