GRAPHITE 58G214 [18/152] Operation settings

Batteries heat up very strongly during charging process. Do not work just after charging has been

nished, wait until the battery cools down to room temperature. It will prevent battery damage.

BATTERY LEVEL INDICATION

Each pressing the switch button turns on battery level indication.

Drill features battery level indication (4 LED diodes) (9). To check battery level status, press the switch

button (8) (g. C). When all diodes are lit, the battery level is high. When 2 diodes are on, the battery is

partially discharged. When only one diode is lit, the battery is discharged and must be recharged.

SPINDLE BRAKE

Drill is equipped with electronic brake that stops the spindle immediately after the switch button (8) is

released. The brake ensures precision when screwing or drilling and prevents free spindle rotation after

switching oﬀ.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

Switching on – press the switch button (8).

Switching o – release the switch button (8).

Each time the switch button (8) is pressed, the LED diode (10) lights up to illuminate the workplace.

ROTATIONAL SPEED CONTROL

Increase or reduce pressure on the switch button (8) to adjust drilling or driving speed while operating.

Speed adjustment allows for a soft start, which prevents dill slipping when drilling holes in gypsum or

glaze, and allows for operation control when screwing in and out.

OVERLOAD CLUTCH

Set the torque adjustment ring (3) in appropriate position to permanently set overload clutch to deﬁned torque

value. When the set torque is reached, overload clutch disconnects automatically. It prevents screwing screws

too deep or damaging the drill.

TORQUE ADJUSTMENT

Ɣ Diﬀerent screws and materials require diﬀerent torque to be applied.

Ɣ The bigger the number corresponding to given position, the bigger is the torque (g. D).

Ɣ Set the torque adjustment ring (3) to appropriate torque value.

Ɣ Always start operation with low torque.

Ɣ Increase the torque gradually until obtaining desired results.

Ɣ Use higher settings to unscrew screws.

Ɣ When drilling, choose setting marked with the drill symbol. The torque is the greatest with this setting.

Ɣ Knowledge how to choose appropriate torque setting comes with practice.

Setting the torque adjustment ring in the drilling position deactivates the overload clutch.

WORKING TOOL INSTALLATION

Ɣ Set the direction selector switch (5) in the middle position.

Ɣ By turning the ring of the quick release chuck (2) counter clockwise (see mark on the ring) you can spread

jaws enough to insert drill or driver bit (g. E).

Ɣ To install working tool, turn the ring of the quick release chuck (2) clockwise and tighten.

Deinstallation of the tool is similar to installation, only the sequence of actions is reversed.

Make sure the tool position is correct when installing drill or driver bit in the quick release chuck. Use

additional magnetic adapter as an extension when using short driver bits.
