GRAPHITE 59G394 [15/98] Operation and maintenance

Ɣ Press the switch button (8) and hold in this position.

Ɣ Press the switch lock button (9) (g. E).

Ɣ Release pressure on the switch (8).

Switching o:

Ɣ Press and release the switch button (8).

ADJUSTMENT OF SANDING BELT POSITION SETTING THE GUIDE ROLLERS PARALLEL

Ɣ Switch the sander on.

Ɣ During sanding belt movement turn the sanding belt adjustment wheel (5) (g. F) so the sanding belt

runs smoothly and does not move aside (g. G).

If you allow the sanding belt to shift to the side (which would mean that roller axes are not parallel),

the belt will be damaged soon.

When using the belt sander try to position the belt surface and surface of processed material in parallel.

Hold the additional grip (1) and main handle (7) ﬁrmly and move the sander back and forth smoothly.

Do not press the belt sander too hard. Pressure must be moderate and uniform on the whole surface

of contact of belt and processed material. Applying too big pressure causes undesirable drop of belt

speed, motor overheating, damage of processed material and parts of the sander. Make periodic

breaks in operation.

ADJUSTMENT OF SANDING BELT SPEED

You can control sanding belt speed by turning and setting in desired position the wheel for adjustment

of sanding belt speed (12). It allows to adjust the power tool working speed to match characteristics of

processed material. Speed control range is 1 to 6.

The bigger the number on the wheel rim (12) (g. I), the greater the belt sander operation speed.

COVER OF SANDING BELT

When lifted, the removable sanding belt cover (14) allows to process with front upper part of the sanding

belt, which facilitates operation in hardly accessible places (g. K).

OPERATION AND MAINTENANCE

Remove the power cord plug from mains socket before commencing any activities related to

installation, adjustment, maintenance or repair of power tool.

Ɣ Always keep the sander and ventilation holes clean.

Ɣ Use brush to remove sanding dust.

Ɣ Clean the belt sander regularly, optimally after each use.

Ɣ Do not use abrasive objects for cleaning the sander.

Ɣ Use soft cloth for cleaning the body.

Ɣ For cleaning never use petrol, solvents or detergents that could damage plastic parts of the sander.

Ɣ When the work is ﬁnished empty the dust bag, wash it in warm water with soap and dry it thoroughly.

REPLACEMENT OF DRIVING BELT

Belt sander will not work properly if driving belt is worn. Belt replacement is necessary.

Ɣ Use screwdriver to unscrew ﬁxing screw of driving belt cover (4) and remove the cover.

Ɣ Remove the driving belt by turning the wheels manually and pulling the belt oﬀ.

Ɣ To install new driving belt do as follows:

– put the belt onto bigger drive wheel,

– rotate wheels to draw the driving belt over smaller drive wheel.

Ɣ Install driving belt cover (4) and tighten ﬁxing screw.

Ensure the driving belt is correctly set on both drive wheels.
