GRAPHITE 59G343 [11/80] Operation settings

MEANING OF SYMBOLS

CAUTION

WARNING

ASSEMBLY/SETTINGS

INFORMATION

EQUIPMENT AND ACCESSORIES

1. Dust bag - 1 pce

2. Sanding paper - 3 pcs

PREPARATION FOR OPERATION

CHOOSING SANDING PAPER

Coarse-grained sanding paper is used for coarse processing of most materials, while ﬁne-grained paper is

used for ﬁnishing works.

Ɣ When the surface is not ﬂat, start the work with coarse-grained sanding paper and continue until the

surface is ﬂat.

Ɣ Next use middle-grained paper to remove traces of coarse processing.

Ɣ To ﬁnish the work use ﬁne-grained sanding paper.

INSTALLING SANDING PAPER

Orbital sander is equipped with pad with so called hook-and-loop and only perforated sanding paper of

appropriate size should be used.

Ɣ Put the sanding paper close to the sander backing pad (8).

Ɣ Place the paper so its (a) holes match holes on the sander backing pad (g. A).

Ɣ Press the sanding paper against the backing pad (8).

Ɣ Ensure that the holes on the sanding paper and backing pad fully match; it ensures possibility of dust

extraction.

The dust bag is located in a plastic case. In order to empty it, the lower section of the plastic case must be

slid down, the dust bag must be taken out of its mount and its contents can be disposed of. The dust bag

must be fastened in the reverse order to the disassembly.

OPERATION / SETTINGS

SWITCHING ON / SWITCHING OFF

The mains voltage must match the voltage on the rating plate of the sander.

Switching on – set the switch button (1) to position I (g. C).

Switching o – set the switch button (1) to position O.

ORBITAL SANDER OPERATION

Ɣ Whole area of backing pad must rest on the processed surface.

Ɣ Turn the sander on and apply moderate pressure; move it on the processed material in circular

movements, in transverse or lengthwise direction.

Ɣ For coarse processing use sanding paper with coarse grain, for ﬁnishing processing use ﬁne-grained

paper. It is best to match the type of sanding paper by trials and errors.

Ɣ When ﬁnishing polishing, reduce pressure, lift the sander above the processed surface and only after

that switch the tool oﬀ.
