inStruction Manual for inverter welder

56H806 / 56H808 / 56H810

INTRODUCTION

INVERTER welders for arc welding and TIG welding (with tungsten electrode in inert gas shielding) are used to

join metal parts with weld penetration.

This is achieved with heat produced by electric arc between electrode tip and welded material.

Parts are joined by melting.

Modern, electronic technical solutions allow to obtain product with specic properties, like low power

The device is equipped with thermal protection against excessive heating due to overloading. Indicator lamp

informs when protection shuts o power supply.

SWITCHING ON

Ensure earthing terminal has good contact with joined parts. Clean surface of joined material where earthing

clamp is installed, when necessary.

Welding current can be adjusted by turning adjustment knob.

WARNING

Ensure ventilation slots are unobstructed.•

Do not leave welder exposed to rain.•

When using high welding current during use of welder, always remember that signicant power consumption •

TECHNICAL DATA:

Technical parameters UNIT 56H806 56H808 56H810

Supply voltage V 230 230 230

Frequency Hz 50/60 50/60 50/60

Open-circuit voltage V 75 78 78

Power consumption kVA 4,9 5,5 6,5

Amperage A 10 - 125 10 - 160 10 - 200

Overload A% 60 25 25

Protection class IP 21 21 21

Electrode diameter mm 1.6 - 4.0 1.6 - 4.0 1.6 - 5.0
