NEVER install this monitor where it is
visible from the driver’s seat, or where it
could injure any vehicle occupant in
case of an accident. Ensure that your
installation does not create risk of
head-strike injury, and that the monitor
will remain securely mounted in the case
of an accident or sudden maneuver.
Before Starting
Disconnect the minus() terminal on the vehicle’s battery.
Precautions
This unit is exclusively for vehicles with a negative ground, 12V power
supply.
Do not open the case. There are no user-serviceable parts inside. If you
require assistance, consult your Clarion dealer or an authorized Clarion
service center.
Use a soft, dry cloth to clean the screen. Never use a rough cloth,
thinner, benzene, alcohol, or other solvent. The screen surface is easy
to scratch-do not rub it when cleaning.
Always use great care when attaching anything to a vehicle! Visually
inspect all sides of any potential screw location to ensure no damage will
occur.
To prevent short circuits during
installation, be sure to disconnect the
battery.
