31
6. SPECIFICATION
Note:
The technical data and the design of the equipment may change for the
sake of technical improvement without prior notice.
VMA573 General Specifications
Power requirement : 12V DC ( 10.8V-15.6V)
Power consumption : 7 watts, power on - typical
0.6 amps (600mA) - typical
Weight : 300 g
Dimension(w x h x d ) : 160.8 x 111.8 x 32.5 mm ( with Bezel )
Included parts : • LCD monitor with wiring harness
• One 1.2M RCA A/V cable
• One power cable
• 3.5Φ Jack to RCA connector cable
• Owner’s manual and installation guide
• Bezel
• Metal insert card
VMA573 Specifications
Display type : Color TFT Active Matrix LCD
Screen size : 5.6”
Pixels : 480 RGB (H) x 234 (V)
Screen resolution : 336,960 dots
Video input lever ( RCA) : 1.0 volts peak to peak
Video format : NTSC, PAL
