Gazer PA40F [9/48] Special aspects of the use

Special aspects of the use

The algorithm of warning about the obstacles during the connection with a

loudspeaker:

• The loudspeaker of the parking system begins to give audio signals when

the automobile is approaching the obstructions by 0.9 m and closer.

• When the distance is being reduced, the interval between audio signals is

becoming shorter, which allows the driver to orient by ear while parking.

• When an obstruction is 0-0.3 m from the automobile, a loudspeaker begins

to give an uninterruptable audio signal, which indicates the danger of the

further movement ahead.

• If while parking, the automobile stops and begins to move away from the

obstruction – audio warnings will cease to sound 1.5 sec later. Thus, the

parking assistant enables the avoidance of excessive audio signals inside

the automobile, if the driver stops in moving ahead for some time or the

obstruction begins to move away from the automobile. In addition to the

above, the system continues to operate and in case of approaching the

obstruction, it will immediately begin to warn about the danger of collision.

The algorithm of warning about the obstacles during the connection with a

Gazer PAD20 optional display:

• When the distance to an obstruction is 0.9-2.5 m, the display shows the

distance to the obstruction in the digital form, as well as the graphic

representation of the sensors triggering.

• The loudspeaker, built into the display, begins to give audio signals when

the automobile is approaching the obstructions by 0.9 m and closer,

together with the digital representation of a distance.

Graphic

representation

only

Audit warning

and graphic

representation
