Gazer CKR4400-F01 [16/57] Dvr function

ENG

Fig. 10 Fig. 11

Note: Current consumption is less than 12 mA in the parking mode when the device is in the standby mode.

DVR function

Settings menu

Gazer surround view system has a 4-channel DVR function that enables it to record 704х576 videos at 30 fps. Video is recorded continuously

thanks to the loop recording function. The system switches to the recoding mode automatically when ACC signal is on or when the shock

sensor is tripped in the parking mode.

Video clips are stored on a micro SD memory card or a USB drive. To view and manage recorded video ﬁ les, go to “Record” in the menu and

select the required ﬁ le from the list. To select or change the storage location of your video ﬁ les, go to “Recording”/“Storage Location” and

then select the appropriate value.

“Record”: recorded ﬁ les list. When selecting the required video ﬁ le from the list, you can block it from loop overwriting. To do this, press the

“Left” button on the remote control and then select “Lock” in the settings menu.

Usage

“Recording”: recording, date and time settings.

“Channel”: select the source of recording. One can select a signle camera or four cameras simultaneously.

“Storage Location”: select a storage device for saving recorded video clips (SD memory card or USB drive).

Note: Do not eject the SD memory card or USB drive when the device is on. This may cause it to malfunction.
