OPERATIONS
46 VXZ768R
English
Setting the car speaker output for
the cellular phone
(Optional TEL-002)
• The factory default setting is “RIGHT”.
• To output the telephone calls, set the cellular
phone interrupt to “ON”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [ ] / [ ] lever to select
“TEL-SP”.
3. Turn the [ROTARY] knob to select “RIGHT” or
“LEFT”.
z RIGHT:
Telephone calls can be heard on the front right
speaker connected to this unit.
z LEFT:
Telephone calls can be heard on the front left
speaker connected to this unit.
4. Press the [ADJ] button to return to the
previous mode.
Cellular phone interrupt setting
If you connect this unit and your cellular phone
with a separately sold unit (TEL-002), you can
listen to your telephone calls on your car
speakers.
• The factory default setting is “OFF”.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [ ] / [ ] lever to select
“TEL-SW”.
3. Turn the [ROTARY] knob to select the setting.
Each time you turn the [ROTARY] knob, the
setting changes in the following order:
OFF ➜ ON ➜ MUTE ➜ OFF...
z OFF:
This unit continues normal operation even when
the cellular phone is used.
Note:
•
If connecting a hands-free kit, please ensure the
setting is “ON” to receive the telephone audio
through the system.
z ON:
You can listen to your telephone calls from the
speakers connected to this unit.
• When listening to your calls on your car speakers,
you can adjust the volume by turning the
[ROTARY] knob.
z MUTE:
The sound from this unit is muted during
telephone calls.
4. Press the [ADJ] button to return to the
previous mode.
Performing a system check
This function verifies the devices hooked up
through CeNET.
1. Press the [ADJ] button to switch to the adjust
mode.
2. Move the [ ] / [ ] lever to select
“SYSTEM”.
3. Press and hold the [ ] button for 1 second
or longer to start the system check.
The digital connection configuration is
automatically checked.
4. When the system check is complete, perform
the speaker setting.
Turn the [ROTARY] knob to select the
speaker system and press the [ ] button.
The display returns to the previous mode.
For details on the speaker setting, refer to
the “System check and speaker setting”
(P. 16).
Note:
•
When the speaker setting has been changed by a
system check, the previously set “AUDIO SETUP”
returns to its default setting.
VXZ768R.book Page 46 Tuesday, December 27, 2005 10:08 PM
