VXZ768R 57
English
11.SPECIFICATIONS
Radio section
Tuning System:
PLL synthesizer tuner
Receiving Frequencies:
FM : 87.5 to 108 MHz (0.05 MHz steps)
MW : 531 to 1602 kHz (9 kHz steps)
LW : 153 to 279 kHz (3 kHz steps)
DVD Player section
System:
Digital Versatile Disc System with CDDA
capable
Usable Discs:
DVD Video Disc, Video CD, Compact disc
Frequency Response:
20 Hz to 22 kHz (±1 dB)
Signal to Noise Ratio: 100 dB
Distortion: 0.01%
Channel Separation: 80 dB
General
Output Power:
4 × 27 W (DIN 45324, +B = 14.4 V)
Power Supply Voltage:
14.4 V DC (10.8 to 15.6 V allowable),
negative ground
Power Consumption: Less than 15 A
Speaker Impedance: 4 Ω (4 to 8 Ω allowable)
Auto Antenna Rated Current: 500 mA or less
Weight:
Main unit: 1.5 kg
Remote control unit:
100 g (including battery)
Dimensions:
Main unit: 178 (W) × 50 (H) × 160 (D) mm
Remote control unit:
54 (W) × 155 (H) × 27 (D) mm
Note:
•
Specifications and design are subject to change without notice for further improvement.
VXZ768R.book Page 57 Tuesday, December 27, 2005 10:08 PM
