SPECIFICATIONS
*
1
UV2A stands for Ultraviolet-induced Multi-domain Vertical Alignment, a photo-alignment technology that ensures
uniform alignment of liquid crystal molecules. *
2
Maximum colours of LCD panel. The number of colours that can be
displayed simultaneously is 16.77 million arbitrary colours out of 1.07 billion colours. *
3
Brightness depends on input
mode and other picture settings. Brightness level will decrease slightly over the lifetime of the product. Due to the
physical limitations of the equipment, it is not possible to maintain a precisely constant level of brightness. *
4
Excluding
the touch sensor part around the LCD panel. *
5
Including anti-glare film on the front. *
6
Approximate distance at
which the glass panel can withstand the impact of a 500-gram iron ball dropped on its centre. *
7
Use a commercially
available connection cable for PC and other video connections. *
8
Video and component video are switchable; use the
menu to select. *
9
The AC power cord is an inlet type. The cable is bundled (3 pins). *
10
Please use only this USB cable
and no other. If connected via a USB hub, a PC may not recognise the PN-80SC5/70SC5 correctly and operation may
be unstable.
13
Model PN-80SC5 PN-70SC5
Installation Landscape
LCD Panel
80-inch-class (203.2 cm diagonal)
UV
2
A *
1
LCD
70-inch-class (176.6
cm diagonal) UV
2
A*
1
LCD
Max. Resolution 1,920 x 1,080 pixels
Max. Display
Colours (approx.)
1.07 billion colours*
2
Pixel Pitch (H x V) 0.923 x 0.923 mm 0.802 x 0.802 mm
Brightness*
3
350 cd/m
2
Contrast Ratio 5,000 : 1 4,000 : 1
Viewing Angle (H/V)*
4
176°/176° (CR
>_
10)
Active Screen Area
(W x H)
1,771.2 x 996.3 mm 1,538.9 x 865.6 mm
Response Time 4 ms (grey to grey, avg.) 8 ms (grey to grey, avg.)
Backlight LED, direct lit LED, edge lit
Touchscreen
Touch Technology IR (infrared blocking detection method)
PC Connection Port USB 2.0
Power Supply Supplied from USB port
Multi Touch 10 points
Protection Glass Thickness: Approx. 3.1 mm*
5
Shock resistance: 130 cm*
6
Touch Pen Function Button N/A (passive pen)
Computer
Input
Video Analogue RGB (0.7 Vp-p) [75Ω]
Synchronisation Horizontal/vertical separation (TTL: positive/negative)
Plug & Play VESA DDC2B
Video Colour System NTSC (3.58 MHz) / NTSC (4.43 MHz) / PAL / PAL60 / SECAM
Input Terminals*
7
PC analogue: Mini D-sub 15-pin x 1, HDMITM x 3 (HDCP and 1080p
compatible, PC / AV signal compatible), 3.5 mm-diameter mini stereo
jack x 1, audio: RCA pin (L/R) x 1, video: RCA pin x 1
*8
, component
video: RCA pin x 1
*8
, RS-232C D-sub 9-pin x 1
Output Terminals*
7
3.5 mm-diameter mini stereo jack x 1
Speaker Output 10 W + 10 W
Mounting
VESA (4 points), 600 x 400 mm,
M6 screw
VESA (4 points), 400 x 400 mm,
M6 screw
Power Supply 100V – 240V AC, 50/60 Hz*
9
LAN terminal 10 BASE-T/100 BASE-TX
Power Consumption 270 W 200 W
Environmental
Conditions
Operating Temperature*
1
5˚C to 35˚C
Operating Humidity 20% to 80% RH (no condensation)
Dimensions (W x D x H) (approx.)
(display only)
1,882 x 127 x 1,139 mm 1,635 x 96 x 998 mm
Weight (approx.) 79 kg 62 kg
Main Accessories
Power cord, remote control unit, battery (AAA size) x 2, set-up manual,
cable clamp x 2, cable clamp (for power cord), USB cable*
10
, eraser, pen
tray, pen tray mounting screw x 5, touch pen, camera mount,
camera mount screw x 2, camera screw, CD-ROM, SHARP Display
Connect license, stand hole protection cover x 2, blank sticker
