SPECIFICATIONS
Model PN-V600A PN-V601A V602A
Installation Landscape/Portrait
LCD Panel
60-inch widescreen
(152.4 cm diagonal), TFT LCD
60-inch widescreen
(152.4 cm diagonal),
UV
2
A LCD
Max. Resolution 1,366 x 768 pixels
Max. Display
Colours (approx.)
16.77 million colours
Pixel Pitch (H x V) 0.973 x 0.973 mm
Brightness*
1
450 cd/m
2
700 cd/m
2
1,500 cd/m
2
Contrast Ratio 4000:1
1,000,000 : 1 (local
dimming set to HIGH)
5,000 : 1 (without local
dimming)
Viewing Angle (H/V) 176°/176° (CR ≥10)
Active Screen Area
(W x H)
1,328.8 x 747.1 mm
Response Time 6 ms (grey to grey, avg.)
Backlight White LED, Full Array
Computer
Input
Video Analogue RGB (0.7 Vp-p) [75], Digital (conforms to DVI 1.0 standards)
Synchronisation Horizontal/vertical separation (TTL: positive/negative)
Plug & Play VESA DDC2B
Power Management VESA DPMS, DVI DMPM
Video Colour System
NTSC (3.58 MHz, 4.43 MHz)*
1
, PAL, PAL60, SECAM
Input Terminals*
2
Standard - PC analogue: Mini D-sub 15-pin x 1, HDMI (1080p
compatible) x 1*
2
, 3.5 mm-diameter mini stereo jack x 1, RS-232C:
D-sub 9-pin x 1,Control Kit jack x 1
Via Optional PN-ZB02 Board - PC digital: DVI-D 24-pin (HDCP
compatible) x 1, PC analogue: BNC x 1*
3
, Video: BNC x 1, S-Video x 1,
Component video: BNC (Y, Cb/Pb, Cr/Pr) x 1*
3
, Audio: RCA pin (L/R) x 2
Output Terminals*
3
Standard - Audio: RCA pin (L/R) x 1, RS-232C: D-sub 9-pin x 1
Via Optional PN-ZB02 Board - PC digital: DVI-D 24-pin x 1, External
speaker: 10W + 10W (6 )
Input/Output Terminals Via Optional PN-ZB02 Board - LAN port (10Base-T/100Base-TX)
Built-in Speakers —
Power Supply 100V – 240V AC, 50/60 Hz
Power Consumption 310 W 480 W 510 W
Environmental
Conditions
Operating Temperature 0°C to 40°C
Operating Humidity 20% to 80% RH (no condensation)
Dimensions (W x D x H) (approx.)
(display only)
1,335.9 x 149.3 x 754.2 mm
Weight (approx.) 41 kg 44 kg
*
1
Requires separately sold PN-ZB02 Interface Expansion Board. *
2
For both PC and AV components. *
3
The analogue
and component BNC terminals are switchable. Use the menu to select.
39
