SPECIFICATIONS
VISION
Model PN-E703 PN-E603
Installation Landscape / Portrait
LCD Panel
70 -inch widescreen (176.6 cm
diagonal) UV
2
A LCD
60 -inch widescreen (152.5 cm
diagonal) UV
2
A LCD
Max. Resolution 1,920 x 1,080 pixels
Max. Display
Colours (approx.)
1.06 billion colours
Pixel Pitch (H x V) 0.802 x 0.802 mm 0.692 x 0.692 mm
Brightness*
1
450 cd/m
2
Contrast Ratio 4,000 : 1
Viewing Angle (H/V) 176°/176° (CR ≥10)
Active Screen Area
(W x H)
1,538.9 x 865.6 mm 1,329.1 x 747.6 mm
Response Time 6 ms (grey to grey, avg.)
Backlight LED, edge lit
Computer
Input
Video
Analogue RGB (0.7 Vp-p) [75], Digital (conforms to DVI 1.0 standards),
DisplayPort 1.1
Synchronisation
Horizontal/vertical separation (TTL: positive/negative), Sync on green,
Composite sync (TTL: positive/negative)
Plug & Play VESA DDC2B
Power Management VESA DPMS, DVI DMPM
Video Colour System NTSC (3.58 MHz, 4.43 MHz), PAL, PAL60, SECAM
Input Terminals*
2
DisplayPort x 1, DVI-I x 1, Mini D-sub 15-pin x 1, HDMI x 2*
3
,
3.5 mm-diameter mini stereo jack x 2, RS-232C x 1
Output Terminals*
3
DisplayPort x 1 (supports video signals only), DVI-D x 1,
3.5 mm-diameter mini stereo jack x 1, RS-232C x 1
Input/Output Terminals LAN port x 1
Built-in Speakers 10 W + 10 W
Power Supply 100V – 240V AC, 50/60 Hz
Power Consumption 225 W 180 W
Environmental
Conditions
Operating Temperature 0°C to 40°C
Operating Humidity 20% to 80% RH (no condensation)
Dimensions (W x D x H) (approx.)
(display only)
1,578 x 39.4 x 916 mm 1,378 x 39.4 x 794 mm
Weight (approx.) 43 kg 32 kg
*
1
Brightness will depend on input mode and other picture settings. Brightness level will decrease over time. Due
to the nature of the equipment, it is not possible to precisely maintain a constant level of brightness. *
2
Use a
commercially available connection cable for PC and other video connections. *
3
For both PC and AV components.
51
