General Settings
63
VZ709E
English
Owner’s manual
Setting the Beep
The sound heard when you make operations is
called “beep”. The system can be set so that it
does not produce this beep sound.
• The factory default setting is “ON”.
Setting the Blink LED
You can set the unit to blink the Blink LED
indication when the DCP (Detachable Control
Panel) is removed.
• The factory default setting is “OFF”.
Confirming the DivX
Registration Code and DivX
URL
When you download a DivX VOD (Video-on-
Demand) file from a web site, entering the
registration code of your playback system may
be required to authorize the file. You can confirm
the registration code of your system and the URL
information by the following operation.
Note:
• The DivX registration code is not displayed when a
disc is set in the DVD player.
Performing the System Check
You can perform the system check by the
following operation.
Setting the Audio
ATTenuation
The audio output can be attenuated when a voice
interrupt of the navigation system arises.
• The factory default setting is “High”.
Note:
• This setting is enabled only when the Navigation
System is connected to this unit.
Setting the Auto Antenna
When an auto antenna which is extended
automatically is used, you can set so that it is
automatically extended/collapsed according to
the power setting of this unit.
Note:
• This setting is enabled only when the Navigation
System is connected to this unit.
Changing the Wall Paper
You can change the wall paper (background
image on the most screens) by selecting it from
the Wall Paper tab screen.
3-1. Touch the [System] key to display the
System tab screen.
3-2. Touch the [ON] or [OFF] key of the Beep
item to turn the Beep function on or off.
3-1. Touch the [System] key to display the
System tab screen.
3-2. Touch the [ON] or [OFF] key of the Blink
LED item to turn the Blink LED function on or
off.
3-1. Touch the [System] key to display the
System tab screen.
3-2. Confirm the displayed information of the
DivX Registration Code and DivX URL
items.
3-1. Touch the [System] key to display the
System tab screen.
3-2. Touch the [C] key to display the next screen.
3-3. Touch the [Check] key of the System Check
item.
A confirmation screen is displayed.
3-4. Touch the [Yes] key to perform the system
check manually.
The system will be restarted after
performing the system check.
3-1. Touch the [System] key to display the
System tab screen.
3-2. Touch the [C] key to display the next screen.
3-3. Touch the [High], [Mid], [Low], or [Mute]
key of the Audio ATT item to set the volume
level when a voice interrupt arises.
3-1. Touch the [System] key to display the
System tab screen.
3-2. Touch the [C] key to display the next screen.
3-3. Touch the [ON] or [OFF] key of the Auto
Antenna item to turn this function on or off.
3-1. Touch the [Wall Paper] key to display the
Wall Paper tab screen.
3-2. Touch the desired Wall Paper key you wish
to set.
The background image of the screen will be
changed to the selected image.
