Step 3- Mount the Handlebar Switch (optional on some models)

WARNING: TO PREVENT SERIOUS INJURY OR DEATH FROM ELEC-

TRICAL FIRE

• Do NOT route electrical cables across sharp edges.

• Do NOT route electrical cables through or near moving parts.

• Do NOT route electrical cables through or near any high heat parts.

• Avoid pinch and wear/abrasion points when installing all electrical cables.

WARNING: TO AVOID INJURY AND PROPERTY DAMAGE

• Use caution when moving or repositioning any vehicle controls so as to not

compromise the safe operation of the ATV. Select a mounting position that will

provide clearance for all vehicle controls.

• Before securing the switch cable with tie wraps, make sure that the handle-

bars have full range of motion.

Fig.3: Contactors for

ATV winch
